Are You Trying to Find the Best Deal on Super Duplex Socket Weld Fittings? To get an estimate right away, send an email to kalpesh@manishasteelcentre.com.
| Description | Class Designation | ||
|---|---|---|---|
| 3000 | 6000 | 9000 | |
| Wall Thickness | SCH 80 / XS | SCH 160 | XXS |
| All Fitting Types | 1/2 – 4 | 1/2 – 2 | 1/2 – 2 |
| 1/2 – 4 | 1/2 – 2 | 1/2 – 2 | |
| 1/2 – 4 | 1/2 – 2 | 1/2 – 2 | |
Genuine Super Duplex Socket Weld Fittings Manufacturer in India As Per Specification
| NPS | Outside Dia of Band | Min WT | Center to End | Min Length of Thread | ||
|---|---|---|---|---|---|---|
| D | G | 90°A | 45° C | B | J | |
| 1¼ | 56 | 3.89 | 44 | 33 | 17 | 18 |
| 1½ | 62 | 4.01 | 51 | 35 | 17.8 | 18.4 |
| 2 | 75 | 4.27 | 60 | 43 | 19 | 19.2 |
| 2½ | 92 | 5.61 | 76 | 52 | 23.6 | 28.9 |
| 1/2 | 33 | 3.18 | 28 | 22 | 10.9 | 13.6 |
| 3/4 | 38 | 3.18 | 33 | 25 | 12.7 | 13.9 |
| 1 | 46 | 3.68 | 38 | 28 | 14.7 | 17.3 |
| 3 | 109 | 5.99 | 86 | 64 | 25.9 | 30.5 |
| 4 | 146 | 6.55 | 106 | 79 | 27.7 | 33 |
| Properties | Duplex Socket Weld Fittings | Super Duplex Socket Weld Fittings |
|---|---|---|
| Material Composition | Approx. 40% austenitic, 60% ferritic | Approx. 50% austenitic, 50% ferritic |
| Cost | Lower | Higher |
| Temperature Range (°C) | -50°C to 200°C | -50°C to 250°C |
| Pressure Rating | Up to 6000 LBS | Up to 9000 LBS |
| Corrosion Resistance | Good | Superior |
| Typical Applications | Less aggressive environments, water treatment, power generation | Marine, offshore, chemical processing, oil & gas |
| Heat Treatment Process | Temperature (°C) | Temperature (°F) |
|---|---|---|
| Solution Annealing | 1020 - 1100 | 1868 - 2012 |
| Post-Weld Heat Treatment (PWHT) | 300 - 800 | 572 - 1472 |
| Stress Relieving | 300 - 450 | 572 - 842 |
| Size (inches) | Pressure Rating (3000 LBS) | Pressure Rating (6000 LBS) | Pressure Rating (9000 LBS) |
|---|---|---|---|
| 1/4" | 6000 psi | 12000 psi | 18000 psi |
| 3/8" | 6000 psi | 12000 psi | 18000 psi |
| 1/2" | 6000 psi | 12000 psi | 18000 psi |
| 3/4" | 6000 psi | 12000 psi | 18000 psi |
| 1/8" | 6000 psi | 12000 psi | 18000 psi |
| 1" | 6000 psi | 12000 psi | 18000 psi |
| 1-1/2" | 5000 psi | 10000 psi | 15000 psi |
| 1-1/4" | 5000 psi | 10000 psi | 15000 psi |
| 2" | 5000 psi | 10000 psi | 15000 psi |
Trusted Super Duplex Socket Weld Fittings Supplier in India in Custom Shapes and Types
Alloy 2507 Socket Weld Elbow
Super Duplex 2507 Socket Weld Tee
Super Duplex Socket Weld Cross
WNR 1.4410 Socket Weld Half Couplings
SAF 2507 Socket Weld Reducing Couplings
Zeron 100 Socket Weld Cap
ASTM A182 UNS S32760 Socket Weld Union
SDSS Socket Weld Plug
Super Duplex SS Socket Weld Reducing Insert
| Properties | Forged | CNC Machined |
|---|---|---|
| Process | Shaped by compressive forces on heated billets | Precision cutting and shaping with CNC machines |
| Strength | Excellent | High precision |
| Durability | Highly durable | Good durability |
| Surface Finish | Rough, requires further finishing | Smooth and precise finish |
| Applications | High-pressure systems | Custom and precision parts |
| STANDARD | UNS | WERKSTOFF NR. |
|---|---|---|
| Super Duplex 2507 | S32750 / S32760 | 1.4410 |
| Grade | C | Mn | Si | Fe | N | Cr | Mo | S | P | Ni |
|---|---|---|---|---|---|---|---|---|---|---|
| S32750 | 0.030 max | 1.20 max | 0.80 max | 58.095 min | 0.24 – 0.32 | 24.00 – 26.00 | 3.00 – 5.00 | 0.020 max | 0.035 max | 6.00 – 8.00 |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 57.61 min | 0.20 – 0.30 | 24.00 – 26.00 | 3.00 – 4.00 | 0.010 max | 0.030 max | 6.00 – 8.00 |
| Element | Properties |
|---|---|
| Yield Strength (0.2%Offset) | Psi – 80000 , MPa – 550 |
| Tensile Strength | Psi – 116000 , MPa – 800 |
| Elongation | 15% |
| Grades | Density (lb/in 3) | Melting Point (°F) | Density (g/cm 3) | Melting Point (°C) |
|---|---|---|---|---|
| S32750 / S32760 | 0.281 | 2460 | 7.8 | 1350 |
| Changes in Price Extra 5 % | |
|---|---|
