ASTM A269 TP316 Tube Sizes
ASTM A269 TP316 Seamless Tubing Standards
ASTM A269 Type 316 Welded Tube Manufacturing Process
ASTM A269 GR TP316 ERW Tube Technique
Benefits of ASTM A269 GR .TP316 Hot Finished Tube
ASTM A269 TP 316 Cold Finished Tube Documentation
ASME SA 269 TP 316 Heat Exchanger Tubes Shape
SA 269 Grade TP316 Heater Tubes Origin
SA 269 Gr 316 Condenser Tubes Services
ASTM A269 TP316 Bright Annealed Tubes Packaging
ASTM A269 Type 316 SS Tubing Finish
ASTM A269 GR TP316 ERW Tube End
ASTM A269 Grade 316 Seamless Austenitic Steel Tubing Testing
ASTM A269 GR TP316 Welded Austenitic Steel Tubing Marking
Are You Looking for the Best ASTM A269 TP316 Tube Deal? If you would like an estimate immediately, send an email to kalpesh@manishasteelcentre.com.
| NPS (inches) | OD | Schedule | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 5S | 10S | 40S | 80S | |||||||
| (mm) | (inches) | Wall Thickness and Weight | ||||||||
| mm (in) | kg/m | mm (in) | kg/m | mm (in) | kg/m | mm (in) | kg/m | |||
| 1 | 33.4 | 1.315 | 1.65 (0.065) | 1.30 | 2.77 (0.109) | 2.09 | 3.38 (0.133) | 2.50 | 4.55 (0.179) | 3.24 |
| 3/4 | 26.7 | 1.050 | 1.65 (0.065) | 1.02 | 2.11 (0.083) | 1.28 | 2.87 (0.113) | 1.68 | 3.92 (0.154) | 2.20 |
| 5 | 141.3 | 5.563 | 2.77 (0.109) | 9.46 | 3.41 (0.134) | 11.6 | 6.56 (0.258) | 21.8 | 9.53 (0.375) | 31.0 |
| 6 | 168.3 | 6.625 | 2.77 (0.109) | 11.3 | 3.41 (0.134) | 13.9 | 7.12 (0.280) | 28.3 | 10.98 (0.432) | 42.6 |
| 8 | 219.1 | 8.625 | 2.77 (0.109) | 14.8 | 3.76 (0.148) | 20.0 | 8.18 (0.322) | 42.5 | 12.70 (0.500) | 64.6 |
| 1 1/4 | 42.2 | 1.660 | 1.65 (0.065) | 1.66 | 2.77 (0.109) | 2.69 | 3.56 (0.140) | 3.39 | 4.86 (0.191) | 4.47 |
| 1 1/2 | 48.3 | 1.900 | 1.65 (0.065) | 1.91 | 2.77 (0.109) | 3.11 | 3.69 (0.145) | 4.06 | 5.08 (0.200) | 5.41 |
| 3 1/2 | 101.6 | 4.000 | 2.11 (0.083) | 5.18 | 3.05 (0.120) | 7.41 | 5.74 (0.226) | 13.6 | 8.08 (0.318) | 18.6 |
| 2 1/2 | 73.0 | 2.875 | 2.11 (0.083) | 3.69 | 3.05 (0.120) | 5.26 | 5.16 (0.203) | 8.64 | 7.01 (0.276) | 11.4 |
| 3 | 88.9 | 3.500 | 2.11 (0.083) | 4.52 | 3.05 (0.120) | 6.46 | 5.49 (0.216) | 11.3 | 7.62 (0.300) | 15.3 |
| 1/8 | 10.3 | 0.405 | - | - | 1.25 (0.049) | 0.28 | 1.73 (0.068) | 0.37 | 2.42 (0.095) | 0.47 |
| 1/4 | 13.7 | 0.540 | - | - | 1.66 (0.065) | 0.49 | 2.24 (0.088) | 0.63 | 3.03 (0.119) | 0.80 |
| 3/8 | 17.2 | 0.675 | - | - | 1.66 (0.065) | 0.63 | 2.32 (0.091) | 0.85 | 3.20 (0.126) | 1.10 |
| 1/2 | 21.3 | 0.840 | 1.65 (0.065) | 0.81 | 2.11 (0.083) | 1.00 | 2.77 (0.109) | 1.27 | 3.74 (0.147) | 1.62 |
| 10 | 273.1 | 10.750 | 3.41 (0.134) | 22.7 | 4.20 (0.165) | 27.8 | 9.28 (0.365) | 60.4 | 12.70 (0.500) | 81.5 |
| 4 | 114.3 | 4.500 | 2.11 (0.083) | 5.84 | 3.05 (0.120) | 8.37 | 6.02 (0.237) | 16.1 | 8.56 (0.337) | 22.3 |
| 2 | 60.3 | 2.375 | 1.65 (0.065) | 2.40 | 2.77 (0.109) | 3.93 | 3.92 (0.154) | 5.45 | 5.54 (0.218) | 7.49 |
| 12 | 323.9 | 12.750 | 3.97 (0.156) | 31.3 | 4.58 (0.180) | 36.1 | 9.53 (0.375) | 73.9 | 12.70 (0.500) | 97.4 |
Genuine ASTM A269 TP316 Tube Manufacturer in India As Per Specification
| Heat Treatment Process | Temperature Range (°C) | Temperature Range (°F) | Duration (minutes) | Cooling Method |
|---|---|---|---|---|
| Solution Annealing | 1040 - 1120°C | 1904 - 2048°F | 30 - 60 minutes | Rapid Air Cooling or Water Quenching |
| Pickling (Post-Weld Treatment) | Not Applicable | Not Applicable | 1 - 2 minutes | Water Quenching |
| Annealing (for High-Temperature Applications) | 850 - 1050°C | 1562 - 1922°F | 30 - 60 minutes | Air Cooling |
| Passivation | Not Applicable | Not Applicable | Varies | Water Rinse |
| Cold Working | Room Temperature | 68°F | Varies | Not Applicable |
| Test Type | Destructive or Non-Destructive |
|---|---|
| Tensile Test | Destructive |
| Hardness Test | Non-Destructive |
| Impact Test | Destructive |
| Ultrasonic Test | Non-Destructive |
| Visual Inspection | Non-Destructive |
| Hydrostatic Test | Destructive |
| Positive Material Identification (PMI) | Non-Destructive |
| Flattening Test | Destructive |
| Flaring Test | Destructive |
| Dimensional Inspection | Non-Destructive |
| OD, inch | WT Tolerance % | OD Tolerance inch(mm) | Length Tolernace inch(mm) | |
|---|---|---|---|---|
| + | - | |||
| > 3 1 /2~< 5 1 /2 | ±10 | ± 0.015(0.38) | 3 /16(4.8) | 0 |
| > 5 1 /2~< 8 | ±10 | ± 0.030(0.76) | 3 /16(4.8) | 0 |
| 8~< 12 | ±10 | ± 0.040(1.01) | 3 /16(4.8) | 0 |
| > 1 1 /2~< 3 1 /2 | ±10 | ± 0.010(0.25) | 3 /16(4.8) | 0 |
| ≤1 /2 | ±15 | ± 0.005 ( 0.13 ) | 1 /8 ( 3.2 ) | 0 |
| > 1 /2~1 1 /2 | ±10 | ±0.005(0.13) | 1 /8(3.2) | 0 |
| 12~< 14 | ±10 | ± 0.050(1.26) | 3 /16(4.8) | 0 |
Trusted ASTM A269 TP316 Tube Supplier in India in Custom Shapes and Types
ASTM A269 TP316 Seamless Tubing
ASTM A269 Type 316 Welded Tube
ASTM A269 Grade 316 Cold Drawn Seamless Tube
ASTM A269 GR TP316 ERW Tube
ASTM A269 GR .TP316 Hot Finished Tube
ASTM A269 TP 316 Cold Finished Tube
ASME SA 269 TP 316 Heat Exchanger Tubes
SA 269 Gr 316 Condenser Tubes
ASTM A269 TP316 Bright Annealed Tubes
| GRADE | UNS NO | SWEDISH SS | JAPANESE JIS | OLD BRITISH | EURONORM | ||
|---|---|---|---|---|---|---|---|
| BS | EN | NO | NAME | ||||
| 316 | S31600 | 2347 | SUS 316 | 316S31 | 58H, 58J | 1.4401 | X5CrNiMo17-12-2 |
| GRADE | YIELD STR 0.2% PROOF (MPA) MIN | TENSILE STR (MPA) MIN | ELONG (% IN 50MM) MIN | HARDNESS | |
|---|---|---|---|---|---|
| ROCKWELL B (HR B) MAX | BRINELL (HB) MAX | ||||
| 316 | 205 | 515 | 40 | 95 | 217 |
| GRADE | DENSITY (KG/M3) | ELASTIC MODULUS (GPA) | SPECIFIC HEAT 0-100°C (J/KG.K) | ELEC RESISTIVITY (NΩ.M) | THERMAL CONDUCTIVITY (W/M.K) | MEAN CO-EFF OF THERMAL EXPANSION (ΜM/M/°C) | |||
|---|---|---|---|---|---|---|---|---|---|
| AT 100°C | AT 500°C | 0-100°C | 0-315°C | 0-538°C | |||||
| 316 | 8000 | 193 | 500 | 74 | 16.3 | 21.5 | 15.9 | 16.2 | 17.5 |
| Cost Variations 5 % extra | |
|---|---|
| Export to | Delivery Time |
| Netherlands | 19-20 |
| Belgium | 6-9 |
| Kuwait | 10 |
| France | 30 |
| Qatar | 7 |
| Philippines | 14 |
| Germany | 15-50 |
| Saudi Arabia | 7 |
| Malaysia | 10 |
| Uk | 30 |
| Indonesia | 9 |
| South Africa | 25-30 |
| Bahrain | 9 |
| Singapore | 8 |
| UAE | 5 days |
| Oman | 5 |
