Are You Looking for the Best ASTM A269 TP316L Tube Deal? If you would like an estimate immediately, send an email to kalpesh@manishasteelcentre.com.
| Nominal Wall | OD Size | Wall Thickness | OD | Length |
|---|---|---|---|---|
| 0.109 (2.77) | 6 (152.4) | +/-10% | +/-0.030 (0.76) | +3/16 (4.76)/-0 |
| 0.065 (1.65) | 1/2 (12.7) | +/-10% | +/-0.005 (0.13) | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 2 (50.8) | +/-10% | +/-0.008 (0.20) | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 2-1/2 (63.5) | +/-10% | +/-0.010 (0.25) | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 1 (25.4) | +/-10% | +/-0.005 (0.13) | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 1-1/2 (38.1) | +/-10% | +/-0.008 (0.20) | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 3 (76.2) | +/-10% | +/-0.010 (0.25) | +1/8 (3.18)/-0 |
| 0.109 (2.77) | 8 (203.2) | +/-10% | +/-0.030 (0.76) | +3/16 (4.76)/-0 |
| 0.083 (2.11) | 4 (101.6) | +/-10% | +/-0.015 (0.38) | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 3/4 (19.1) | +/-10% | +/-0.005 (0.13) | +1/8 (3.18)/-0 |
Genuine ASTM A269 TP316L Tube Manufacturer in India As Per Specification
| OD (inches) | Wall Thickness (inches) | OD (mm) | Wall Thickness (mm) |
|---|---|---|---|
| 1/4" to 2" | 0.035" to 0.250" | 6.35 mm to 50.80 mm | 0.89 mm to 6.35 mm |
| 1/2" to 4" | 0.035" to 0.500" | 12.70 mm to 101.60 mm | 0.89 mm to 12.70 mm |
| 1" to 8" | 0.065" to 0.750" | 25.40 mm to 203.20 mm | 1.65 mm to 19.05 mm |
| 1/4" to 1 1/2" | 0.040" to 0.200" | 6.35 mm to 38.10 mm | 1.02 mm to 5.08 mm |
| 3/8" to 3" | 0.045" to 0.375" | 9.53 mm to 76.20 mm | 1.14 mm to 9.53 mm |
| Testing Type | Destructive or Non-Destructive |
|---|---|
| Eddy Current Testing | Non-Destructive |
| Chemical Composition Analysis | Non-Destructive |
| Hydrostatic Testing | Non-Destructive |
| Dimensional Inspection | Non-Destructive |
| Surface Inspection | Non-Destructive |
| Ultrasonic Testing | Non-Destructive |
| Tensile Testing | Destructive |
| Hardness Testing | Destructive |
| Flattening Test | Destructive |
Trusted ASTM A269 TP316L Tube Supplier in India in Custom Shapes and Types
ASTM A269 TP316L Seamless Tubing
ASTM A269 Type 316L Welded Tube
ASTM A269 Grade 316L Cold Drawn Seamless Tube
ASTM A269 GR TP316L ERW Tube
ASTM A269 GR .TP316L Hot Finished Tube
ASTM A269 TP 316L Cold Finished Tube
ASME SA 269 TP 316L Heat Exchanger Tubes
SA 269 Grade TP316L Condenser Tubes
SA 269 Gr 316L Bright Annealed Tubes
| Heat Treatment Process | Temperature Range (°C) | Temperature Range (°F) |
|---|---|---|
| Solution Annealing | 1010°C to 1120°C | 1850°F to 2050°F |
| Annealing (High-Temp) | 850°C to 1050°C | 1562°F to 1922°F |
| Stress Relieving | 550°C to 700°C | 1022°F to 1292°F |
| Pickling and Passivation | Not Applicable | Not Applicable |
| Bright Annealing | 1040°C to 1120°C | 1904°F to 2050°F |
| Tempering | 200°C to 350°C | 392°F to 662°F |
| Property | Cold-Drawn | Hot-Finished |
|---|---|---|
| Manufacturing Process | Processed at room temperature | Processed at high temperature (typically 900°C to 1100°C) |
| Dimensional Tolerances | Very tight (±0.02 mm) | Looser (±0.1 mm) |
| Surface Finish | Smooth, bright finish | Rougher surface finish |
| Strength | Higher tensile strength | Lower tensile strength |
| Ductility | Lower ductility | Higher ductility |
| Cost | Generally higher | Generally lower |
| GRADE | UNS NO | SWEDISH SS | JAPANESE JIS | OLD BRITISH | EURONORM | ||
|---|---|---|---|---|---|---|---|
| BS | EN | NO | NAME | ||||
| 316L | S31603 | 2348 | SUS 316L | 316S11 | - | 1.4404 | X2CrNiMo17-12-2 |
| GRADE | YIELD STR 0.2% PROOF (MPA) MIN | TENSILE STR (MPA) MIN | ELONG (% IN 50MM) MIN | HARDNESS | |
|---|---|---|---|---|---|
| ROCKWELL B (HR B) MAX | BRINELL (HB) MAX | ||||
| 316L | 170 | 485 | 40 | 95 | 217 |
| GRADE | DENSITY (KG/M3) | SPECIFIC HEAT 0-100°C (J/KG.K) | ELEC RESISTIVITY (NΩ.M) | ELASTIC MODULUS (GPA) | THERMAL CONDUCTIVITY (W/M.K) | MEAN CO-EFF OF THERMAL EXPANSION (ΜM/M/°C) | |||
|---|---|---|---|---|---|---|---|---|---|
| AT 100°C | AT 500°C | 0-100°C | 0-315°C | 0-538°C | |||||
| 316L | 8000 | 500 | 74 | 193 | 16.3 | 21.5 | 15.9 | 16.2 | 17.5 |
| Cost Variations 5 % extra | |
|---|---|
