Do You Want to Know the Latest Monel Price Per Kg? To receive a quick quote, email kalpesh@manishasteelcentre.com
| Material | Price In INR | Price In USD |
|---|---|---|
| Monel Alloy 400 | ₹ 4000 - Per kg | $ 50 - Per kg |
Manisha Steel Centre Most Reliable Monel Supplier in India Since 1997, Keep and Provide a Range of Monel Products
Fittings Sizes
Flanges Sizes
Pipe and Tube Sizes
Round Bar Size
Sheet and Plate Sizes
Fasteners Sizes
Forged Fittings Sizes
Tube Fittings Sizes
Value Added Services
Packaging
Application
Features
| Thermal Conductivity | 21.8 W/m-K |
|---|---|
| Heat Capacity | 0.427 J/g-°C |
| CTE, linear 20°C | 13.9 µm/m-°C |
| Liquidus | 1350 °C |
| Solidus | 1300 °C |
| Grade | Carbon | Iron | Nickel | Manganese | Silicon | Sulfur | Copper | Titanium | Aluminum |
|---|---|---|---|---|---|---|---|---|---|
| Monel 400 | 0.3 | 1.0–2.5 | 63.0 | 2.0 | 0.5 | 0.02 | 28.0–34.0 | – | 0.50 |
| Monel K500 | 0.25 | 0.5 – 2 | 63.0 | 1.5 | 0.5 | 0.010 | 27.0 – 33.0 | 0.35 – 0.85 | 2.3 – 3.15 |
| Grade | Density | Yield Strength | Melting Point | Tensile Strength | Elongation |
|---|---|---|---|---|---|
| Monel K500 | 8.44 g/cm3 | Psi 115000, MPa 790 | 1350 °C (2460 °F) | Psi 160000, MPa 1100 | 20 % |
| Monel 400 | 8,8 g/cm3 | Psi 35,000, MPa 240 | 1350 °C (2460 °F) | Psi 80,000, MPa 550 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | BS | AFNOR | JIS | EN | GOST |
|---|---|---|---|---|---|---|---|
| Monel K500 | 2.4375 | N05500 | – | – | – | – | – |
| Monel 400 | 2.4360 | N04400 | NA 13 | NU-30M | NW 4400 | NiCu30Fe | МНЖМц 28-2,5-1,5 |
| Electrical Resistance | 5.47e-005 ohm-cm |
|---|---|
| Curie Temperature | 35°C |
| Alloy 400 | N04400 | B 127, B 164 / SB 164,SB 127 |
|---|---|---|
| Alloy 404 | N04404 | SB 164 / B 164 |
| Alloy 401 | N04401 | |
| Alloy R-405 | N04405 | |
| Alloy K-500 | N05500 | SB 865 / B 865 |
| Property | Monel 400 | Monel K500 |
|---|---|---|
| Grade | 400 | K500 |
| Corrosion Resistance | Excellent Corrosion resistance | Excellent Corrosion resistance |
| Strength | Tensile strength ~70,000 psi | Tensile strength ~85,000 psi |
| Hardness | 170-200 HB | 250-300 HB |
| Heat Treatment | 1,500 to 1,600°F | 980 to 1,040°C |
| Applications | chemical processing, Marine engineering, pump shafts | Marine engineering,marine, aerospace |
| Monel Alloy | Temperature Range (°F) | Temperature Range (°C) |
|---|---|---|
| Monel 400 | -418°F - 896°F | -250°C - 480°C |
| Monel K500 | -418°F - 1202°F | -250°C - 650°C |
Monel Pipe Fittings
| Changes in Price Extra 5 % |
|
|---|---|
| Export to | Shipping Time in Days |
| Sri lanka | 6 |
| Netherlands | 45-60 |
| Japan | 7 |
| The Republic Of Congo | 45-60 |
| Belgium | 21 |
| Sudan | 30 |
| Norway | 45 |
| Angola | 45 |
| Jordan | 21 |
| Germany | 45 |
| Cyprus | 45 |
| Canada | 45 |
| Gabon | 45-60 |
| Panama | 45 |
| Mexico | 45 |
