Are You Looking for ASTM A270 TP304 Tube at the Best Price? In order to obtain an estimate immediately, send an email to kalpesh@manishasteelcentre.com.
| Nominal Size | Price per Meter (USD) |
|---|---|
| 1/4" x 0.028" | US $8.00 |
| 3/8" x 0.035" | US $9.50 |
| 1/2" x 0.035" | US $11.00 |
| 3/4" x 0.049" | US $12.00 |
| 1" x 0.065" | US $14.00 |
| 1-1/4" x 0.065" | US $15.00 |
| 1-1/2" x 0.065" | US $18.00 |
| 2" x 0.083" | US $20.00 |
| 2-1/2" x 0.083" | US $22.00 |
| 3" x 0.083" | US $24.00 |
Genuine ASTM A270 TP304 Tube Manufacturer in India As Per Specification
| Nominal Size | Tube Diameter (OD) | Wall Thickness | ||
|---|---|---|---|---|
| INCH | MM | INCH | MM | |
| 1/4" x 0.028" | 1/4" | 6.35 | 0.028" | 0.71 |
| 3/8" x 0.035" | 3/8" | 9.53 | 0.035" | 0.89 |
| 1/2" x 0.035" | 1/2" | 12.70 | 0.035" | 0.89 |
| 3/4" x 0.049" | 3/4" | 19.05 | 0.049" | 1.24 |
| 1" x 0.065" | 1" | 5.40 | 0.065" | 1.65 |
| 1-1/4" x 0.065" | 1-1/4" | (31.75 | 0.065" | 1.65 |
| 1-1/2" x 0.065" | 1-1/2" | 38.10 | 0.065" | 1.65 |
| 2" x 0.083" | 2" | 50.80 | 0.083" | 2.11 |
| 2-1/2" x 0.083" | 2-1/2" | 63.50 | 0.083" | 2.11 |
| 3" x 0.083" | 3" | 76.20 | 0.083" | 2.11 |
| Nominal Wall | OD Size | OD | WT | Length |
|---|---|---|---|---|
| 0.065 (1.65) | 1-1/2 (38.1) | +/-0.008 (0.20) | +/-10% | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 2 (50.8) | +/-0.008 (0.20) | +/-10% | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 2-1/2 (63.5) | +/-0.010 (0.25) | +/-10% | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 1 (25.4) | +/-0.005 (0.13) | +/-10% | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 3/4 (19.1) | +/-0.005 (0.13) | +/-10% | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 3 (76.2) | +/-0.010 (0.25) | +/-10% | +1/8 (3.18)/-0 |
| 0.109 (2.77) | 6 (152.4) | +/-0.030 (0.76) | +/-10% | +3/16 (4.76)/-0 |
| 0.083 (2.11) | 4 (101.6) | +/-0.015 (0.38) | +/-10% | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 1/2 (12.7) | +/-0.005 (0.13) | +/-10% | +1/8 (3.18)/-0 |
| 0.109 (2.77) | 8 (203.2) | +/-0.030 (0.76) | +/-10% | +3/16 (4.76)/-0 |
| Heat Treatment Process | Temperature Range |
|---|---|
| Solution Annealing | 1,030°C to 1,100°C (1,886°F to 2,012°F) |
| Stress Relieving | 500°C to 750°C (932°F to 1,382°F) |
| Solution Quenching | Above 1,000°C (1,832°F) |
| Annealing | 800°C to 900°C (1,472°F to 1,652°F) |
Trusted ASTM A270 TP304 Tube Supplier in India in Custom Shapes and Types
ASTM A270 TP 304 Welded Sanitary Tubing
ASME SA 270 TP 304 Seamless Sanitary Tubing
ASME SA270 Grade 304 Hygienic Tubing
A270 Type 304 Pharmaceutical Tubing
ASME Sa270 Gr 304 Biopharm Tubing
ASTM A270 TP304 Biopharmaceutical Tubing
| Testing Method | Type of Test |
|---|---|
| Tensile Testing | Destructive |
| Flattening Test | |
| Bend Test | |
| Hardness Testing | |
| Visual Inspection | Non-Destructive |
| Dimensional Testing | |
| Hydrostatic Test | |
| Ultrasonic Testing (UT) | |
| Eddy Current Testing |
| Finish Type | Surface Roughness (Ra) |
|---|---|
| Mechanical Polish | Ra ≤ 0.5 µm (20 µin) |
| Electropolished | Ra ≤ 0.25 µm (10 µin) |
| Pickled | Ra ≤ 0.5 µm (20 µin) |
| Mill Finish | Ra ≤ 0.8 µm (32 µin) |
| Passivated | Ra ≤ 0.5 µm (20 µin) |
| Grade | Unified Numbering System | Swedish SS | Japanese Industrial Standards | Euronorm | Old British | ||
|---|---|---|---|---|---|---|---|
| No | Name | British Standards | European Standards | ||||
| 304 | S30400 | 2332 | SUS 304 | 1.4301 | X5CrNi18-10 | 304S31 | 58E |
| Material | Yield Strength | Tensile Strength | Heat | Temperure | Elongation |
|---|---|---|---|---|---|
| Ksi (MPa) | Ksi (MPa) | Treatment | º F(º C) | ||
| TP304 | 30(205) | 75(515) | Solution | 1900 (1040) | 35 |
| Grade | Density | Elastic Modulus | Specific Heat | Electrical Resistivity | Thermal Conductivity | Mean Coefficient of Thermal Expansion | |||
|---|---|---|---|---|---|---|---|---|---|
| at 100°C | at 500°C | 0-100°C | 0-315°C | 0-538°C | |||||
| 304 | 8000 | 193 | 500 | 720 | 16.2 | 21.5 | 17.2 | 17.8 | 18.4 |
| Cost Variations 5 % extra | |
|---|---|
| Export to | Delivery Time |
| UAE | 5 days |
| Qatar | 7 |
| Netherlands | 19-20 |
| Uk | 30 |
| Kuwait | 10 |
| Germany | 15-50 |
| Oman | 5 |
| Belgium | 6-9 |
| Saudi Arabia | 7 |
| Malaysia | 10 |
| South Africa | 25-30 |
| Bahrain | 9 |
| Singapore | 8 |
| France | 30 |
