Are you trying to find the best price on Pure Nickel per kilogram? Get a quote right away by sending an email. kalpesh@manishasteelcentre.com
| Price List | Price in USD | Price in INR (Indian Rupees) |
|---|---|---|
| Pure Nickel, 99.9% | US $ 25.00 | INR 2,000.00 |
| Nickel Alloy 201 | US $ 35.00 | INR 2,800.00 |
| Nickel 200 | US $ 28.00 | INR 2,240.00 |
| STANDARD | WERKSTOFF NR. | UNS | GOST | BS | JIS | EN | AFNOR |
|---|---|---|---|---|---|---|---|
| Russia | North America | Russia | United Kingdom | Japan | Europe | France | |
| Nickel 201 | 2.4068 | N02201 | НП-2 | NA 12 | NW 2201 | LC-Ni 99 | - |
| Nickel 200 | 2.4066 | N02200 | НП-2 | NA 11 | NW 2200 | Ni 99.2 | N-100M |
| Grade | Mn | Ni | C | Fe | Ti | Mg | Si | S | Cu |
|---|---|---|---|---|---|---|---|---|---|
| Nickel 200 | 0.35 Max | 99.0 Min | 0.15 Max | 0.4 Max | - | - | 0.1 Max | 0.01 Max | 0.25 Max |
| Nickel 201 | 0.35 Max | 99.0 Min | 0.02 Max | 0.4 Max | 0.1 Max | 0.15 Max | 0.2 Max | 0.01 Max | 0.25 Max |
| Grades | Yield Strength (psi) | Tensile Strength (psi) | Elongation in (%) | Reduction of Area (%) | Brinell Hardness (BHN) |
|---|---|---|---|---|---|
| Nickel 200 | Psi to 21500 , MPa to 148 | Psi to 67000 , MPa to 462 | 1446 °C (2635 °F) | 8.9 G/Cm3 | 45 % |
| Nickel 201 | Psi to 21500 , MPa to 148 | Psi to 67000 , MPa to 462 | 1446 °C (2635 °F) | 8.9 G/Cm3 | 45 % |
Nickel Alloy Pipe Fittings
Nickel Alloy Flanges
Nickel Alloy Round Bar
| Property | Nickel Alloy | Stainless Steel |
|---|---|---|
| Temperature (°C) | Up to 1200 | Up to 800 |
| Density (g/cm³) | 8.44 to 8.9 g/cm³ | 7.75 to 8.03 g/cm³ |
| Yield Strength () | 250 to 700 MPa | 200 to 600 MPa |
| Magnetic Permeability | ≤ 1.01 | 1.01 to 100 |
| Corrosion resistance | <0.01 excellent Corrosion resistance | 0.1 to 1.0 moderate resistance |
| Grades | Inconel 600, Incoloy 825, Inconel 625, Nickel 201 | 304, 316, |
| Optical Properties | English | Metric |
|---|---|---|
| Reflection Coefficient | 0.413 | 0.413 |
| Emissivity (0-1) | 0.19 Temperature 1830 °F | 0.19 Temperature 1000 °C |
| 0.080 Temperature 392 - 752 °F | 0.080 Temperature 200 - 400 °C |
| Physical Properties | Metric | English |
|---|---|---|
| Shear Modulus | 76.0 GPa | 11000 ksi |
| Density | 8.88 g/cc | 0.321 lb/in³ |
| Poissons Ratio | 0.31 | 0.31 |
| Modulus of Elasticity | 207 GPa | 30000 ksi |
| Electrical Properties | English | Metric |
|---|---|---|
| Electrical Resistivity | 0.00000640 ohm-cm | 0.00000640 ohm-cm |
| Curie Temperature | 676 °F | 358 °C |
| Magnetic Permeability | 1240 | 1240 |
| Thermal Properties | Metric | English |
|---|---|---|
| Heat of Fusion | 305.6 J/g | 131.5 BTU/lb |
| CTE, linear | 13.1 µm/m-°C Temperature 20.0 °C | 7.28 µin/in-°F Temperature 68.0 °F |
| Heat of Vaporization | 5862 J/g | 2522 BTU/lb |
| Thermal Conductivity | 60.7 W/m-K | 421 BTU-in/hr-ft²-°F |
| Specific Heat Capacity | 0.460 J/g-°C | 0.110 BTU/lb-°F |
| Boiling Point | 2913 °C | 5275 °F |
| Melting Point | 1455 °C | 2651 °F |
Reputable Nickel Alloy Supplier in India Sustain and Provide a Range of Nickel Alloy Products Since 1997
Pipe and Tube Sizes
Round Bar Size
Fittings Sizes
Flanges Sizes
Forged Fittings Sizes
Tube Fittings Sizes
Sheet and Plate Sizes
Fasteners Sizes
Application
Features
Value Added Services
Packaging
| Price Changes 5 % extra |
|
|---|---|
| Export to | DeliveryTime in Days |
| Netherlands | 9 |
| South Africa | 25-30 |
| Germany | 8 |
| USA | 40-60 |
| Qatar | 7 |
| Italy | 30 |
| Philippines | 14 |
| France | 30 |
| UAE | 5 days |
| Uk | 30 |
| Indonesia | 9 |
| Kuwait | 10 |
| Saudi Arabia | 7 |
| Belgium | 10 |
| Oman | 5 |
