Are You Trying to Find the Best Deal on ASTM A270 TP316 Tube? In order to obtain an estimate immediately, send an email to kalpesh@manishasteelcentre.com.
| Tube Size (OD x WT) | Length | Price (USD per Meter) |
|---|---|---|
| 1/4" x 0.035" | 6 meters | US $10.50 |
| 1/2" x 0.065" | 6 meters | US $18.20 |
| 3/4" x 0.090" | 6 meters | US $25.50 |
| 1" x 0.120" | 6 meters | US $40.00 |
| 1-1/2" x 0.150" | 6 meters | US $65.00 |
| 2" x 0.250" | 6 meters | US $90.00 |
Genuine ASTM A270 TP316 Tube Manufacturer in India As Per Specification
| Outer Diameter | Thickness |
|---|---|
| 1 | 0.065 |
| 1 1/2 | 0.065 |
| 2 | 0.065 |
| 2 | 0.065 |
| 2 1/2 | 0.065 |
| 1 1/2 | 0.065 |
| 2 1/2 | 0.065 |
| 1/2 | 0.065 |
| 6 | 0.109 |
| 8 | 0.109 |
| 3/4 | 0.065 |
| 4 | 0.083 |
| 3/4 | 0.065 |
| 1/2 | 0.065 |
| 1 | 0.065 |
| 3 | 0.065 |
| 3 | 0.065 |
| 6 | 0.109 |
| 4 | 0.083 |
| 8 | 0.109 |
| Heat Treatment Process | Temperature Range (°C) |
|---|---|
| Annealing | 1040°C - 1120°C |
| Solution Annealing | 1040°C - 1100°C |
| Passivation | Below 70°C |
| Pickling (for removal of scale) | Up to 450°C |
Trusted ASTM A270 TP316 Tube Supplier in India in Custom Shapes and Types
ASTM A270 TP 316 Welded Sanitary Tubing
ASME SA 270 TP 316 Seamless Sanitary Tubing
ASME SA270 Grade 316 Hygienic Tubing
A270 Type 316 Pharmaceutical Tubing
ASME Sa270 Gr 316 Biopharm Tubing
ASTM A270 TP316 Biopharmaceutical Tubing
| Finish Type | Surface Roughness (Ra) |
|---|---|
| Pickled | Ra ≤ 0.5 µ (20 µin) |
| Mill Finish | Ra ≤ 0.8 µ (32 µin) |
| Mechanical Polish | Ra ≤ 0.5 µ (20 µin) |
| Electropolished | Ra ≤ 0.25 µ (10 µin) |
| Passivated | Ra ≤ 0.5 µ (20 µin) |
| Testing ethod | Type of Test |
|---|---|
| Visual Inspection | Non-Destructive |
| Diensional Testing | |
| Hydrostatic Test | |
| Ultrasonic Testing (UT) | |
| Eddy Current Testing | |
| Tensile Testing | Destructive |
| Flattening Test | |
| Bend Test | |
| Hardness Testing |
| Grade | Unified Numbering System | Swedish SS | Japanese Industrial Standards | GOST | Euronorm | Old British | ||
|---|---|---|---|---|---|---|---|---|
| No | Name | British Standards | European Standards | |||||
| 316 | S30403 | 2332 | SUS 316 | 03Х18Н11 | 1.4306 / 1.4307 | X5CrNi18-10 | 304S31 | 58E |
| Material | Yield Strength | Tensile Strength | Heat Treatment | Temperure | Elongation |
|---|---|---|---|---|---|
| Ksi (MPa), Min. | Ksi (MPa), Min. | Min. | |||
| º F(º C) | |||||
| TP316 | 30(205) | 75(515) | Solution | 1900(1040) | 35 |
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | Thermal Conductivity (W/m.K) | Mean Coefficient of Thermal Expansion (μm/m/°C) | |||
|---|---|---|---|---|---|---|---|---|---|
| at 100°C | at 500°C | 0-100°C | 0-315°C | 0-538°C | |||||
| ASTM A270 TP316 | 8000 | 193 | 500 | 720 | 16.2 | 21.5 | 17.2 | 17.8 | 18.4 |
| Cost Variations 5 % extra | |
|---|---|
| Export to | Delivery Tie |
| Singapore | 8 |
| France | 30 |
| UAE | 5 days |
| Qatar | 7 |
| Netherlands | 19-20 |
| Uk | 30 |
| Kuwait | 10 |
| Gerany | 15-50 |
| Oan | 5 |
| Belgiu | 6-9 |
| Saudi Arabia | 7 |
| alaysia | 10 |
| South Africa | 25-30 |
| Bahrain | 9 |
