Are You Trying to Find the Best Deal on ASTM A554 TP304L Tube? To get an estimate right away, send an email to kalpesh@manishasteelcentre.com.
| Size (Inches) | Wall Thickness (Inches) | Price per Meter (USD) |
|---|---|---|
| 1/4" (0.25) | 0.035 | US $3.50 |
| 1/2" (0.50) | 0.065 | US $4.20 |
| 3/4" (0.75) | 0.065 | US $5 |
| 1" (1.00) | 0.083 | US $6.30 |
| 1.5" (1.50) | 0.083 | US $9 |
| 2" (2.00) | 0.120 | US $12 |
| 3" (3.00) | 0.120 | US $18.50 |
| 4" (4.00) | 0.120 | US $24 |
Genuine ASTM A554 TP304L Tube Manufacturer in India As Per Specification
| Largest Specified OD (in Inches/ mm) | OD | Wall Thickness | ||
|---|---|---|---|---|
| inches | mm | inches | mm | |
| ½ to 1 (12.7 to 25.4) | 00.005 | 00.13 | 00.020 to 0.065 | 00.51 to 1.65 |
| ½ to 1 (12.7 to 25.4) | 00.010 | 00.25 | 0.065 to 0.134 | 1.65 to 3.40 |
| 2 to 2½ | 00.012 | 00.30 | 00.032 to 0.065 | 00.81 to 1.65 |
| 1 to 1½ | 00.010 | 00.25 | 0.065 to 0.134 | 1.65 to 3.40 |
| 2 to 2½ | 00.013 | 00.33 | 0.065 to 0.109 | 1.65 to 2.77 |
| 2 to 2½ | 00.014 | 00.36 | 0.109 to 0.165 | 2.77 to 4.19 |
| 2½ to 3½ | 00.014 | 00.36 | 00.032 to 0.165 | 00.81 to 4.19 |
| 2½ to 3½ | 00.020 | 00.51 | 0.165 | 4.19 |
| 3½ to 5 | 00.025 | 00.64 | 0.165 | 4.19 |
| 5 to 7½ | 00.025 | 00.64 | 00.049 to 0.250 | 1.24 to 6.35 |
| 1 to 1½ | 00.008 | 00.20 | 00.025 to 0.065 | 00.64 to 1.65 |
| 1½ to 2 | 00.012 | 00.30 | 0.083 to 0.149 | 2.11 to 3.78 |
| 5 to 7½ | 00.030 | 00.76 | 0.250 | 6.35 |
| 3½ to 5 | 00.020 | 00.51 | 00.035 to 0.165 | 00.89 to 4.19 |
| 1½ to 2 | 00.010 | 00.25 | 00.025 to 0.049 | 00.64 to 1.24 |
| Under ½ (12.7) | 00.004 | 00.10 | 00.020 to 0.049 | 00.51 to 1.24 |
| 1½ to 2 | 00.011 | 00.28 | 0.049 to 0.083 | 1.24 to 2.11 |
| 7½ to 16 | 00.00125 in./ in. or mm/ mm of circumstances | all | all | |
Trusted ASTM A554 TP304L Tube Supplier in India in Custom Shapes and Types
ASTM A554 TP304L Round Tube
ASTM A554 GR TP304L Square Tube
ASTM A554 Grade Mt304L Rectangular Tube
ASTM A554 GR .TP304L Mechanical Tubing
ASTM A554 TP 304L Welded Tube
ASME SA 554 TP 304L ERW Tube
| Acid/Condition | Corrosion Resistance |
|---|---|
| Mild Acids (citric, acetic) | Good resistance |
| Sulfuric Acid (diluted) | Moderate resistance (at low concentrations) |
| Sulfuric Acid (concentrated) | Poor resistance (at high concentrations) |
| Hydrochloric Acid (diluted) | Moderate resistance (at low concentrations) |
| Hydrochloric Acid (concentrated) | Poor resistance |
| Nitric Acid (diluted) | Good resistance |
| Nitric Acid (concentrated) | Limited resistance |
| Chloride Exposure (sea water) | Poor resistance to pitting and crevice corrosion |
| Heat Treatment Process | Temperature Range (°C) |
|---|---|
| Solution Annealing | 1010 – 1120°C |
| Cooling | < 800°C (water or air quenching) |
| Post-Heating | 800 – 870°C |
| Hardening | - |
| Temper | 400 – 750°C |
| Grade | Unified Numbering System | Swedish SS | Japanese Industrial Standards | GOST | Euronorm | Old British | ||
|---|---|---|---|---|---|---|---|---|
| No | Name | British Standards | European Standards | |||||
| 304L | S30403 | 2332 | SUS 304L | 03Х18Н11 | 1.4306 / 1.4307 | X5CrNi18-10 | 304S31 | 58E |
| Material | Tensile Strength | Yield Strength | Temperure | Heat | Elongation |
|---|---|---|---|---|---|
| Ksi (MPa), Min. | Ksi (MPa), Min. | Min. º F(º C) | Treatment | ||
| ASTM A554 304L | 70(485) | 25(170) | 1900 (1040) | Solution | 35 |
| Grade | Density (kg/m3) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | Elastic Modulus (GPa) | Thermal Conductivity (W/m.K) | Mean Coefficient of Thermal Expansion (μm/m/°C) | |||
|---|---|---|---|---|---|---|---|---|---|
| at 100°C | at 500°C | 0-100°C | 0-315°C | 0-538°C | |||||
| ASTM A554 TP304L | 8000 | 500 | 720 | 193 | 16.2 | 21.5 | 17.2 | 17.8 | 18.4 |
| Method | Purpose |
|---|---|
| Visual Inspection | Detect surface defects |
| Ultrasonic Testing (UT) | Detect internal defects |
| Radiographic Testing (RT) | Detect internal voids or cracks |
| Dye Penetrant Inspection (DPI) | Detect surface cracks and voids |
| Magnetic Particle Inspection (MPI) | Detect surface and near-surface cracks |
| Bend Testing | Assess ductility and strength |
| Hardness Testing | Evaluate mechanical properties |
| Tensile Testing | Test strength under stress |
| Leak Testing | Check for leakage in pressurized systems |
| Metallographic Examination | Inspect microstructure of the weld |
| Changes in Price Extra 5 % | |
|---|---|
| Export to | Shipping Time in Days |
| Malaysia | 10 |
| Qatar | 7 |
| South Africa | 25-30 |
| Indonesia | 9 |
| UAE | 5 days |
| Saudi Arabia | 7 |
| Italy | 30 |
| Singapore | 8 |
| USA | 40-60 |
| Oman | 5 |
| France | 30 |
| Philippines | 14 |
| Bahrain | 9 |
| Kuwait | 10 |
| Uk | 30 |
