ASTM A234 WP11 Fittings

Home|ASTM A234 WP11 Fittings

Prominent ASME SA 234 Grade WP11 Class 1 Buttweld Fittings Manufacturer in India At Fair Price

ASTM A234 WP11 Fittings Specification
Manisha Steel Centre

Table of Content

ASTM A234 WP11 Fittings Specification
ASTM A234 WP11 Fittings Sizes

ASTM A234 WP11 Fittings Sizes

  • Size : 1⁄₂ to NPS 48”
  • Schedule : 10 - 160
  • End : Bevelled,Compound Bevel,Plain Bevel,Buttweld
ASTM A234 WP11 Cl2 Manufacturing Standards

ASTM A234 WP11 Cl2 Manufacturing Standards

  • ASTM A234
  • ASME SA234

ASTM A234 WP11 Cl1 Benefits

ASTM A234 WP11 Cl1 Benefits

  • high strength
  • Durability
  • corrosion resistance
ASTM A234 Gr WP11 C11 Process

ASTM A234 Gr WP11 C11 Process

  • Testing
  • Shaping
  • Cooling
ASTM A234 Grade WP11 Class 1 Types

ASTM A234 Grade WP11 Class 1 Types

  • Elbow , Tee
  • Stub End , Pipe Bend
  • Reducer , Cap , Cross
ASTM A234 Gr. WP11 C1.1 International Standards

ASTM A234 Gr. WP11 C1.1 International Standards

  • ANSI/ASME B16.9
  • B16.28
ASME SA 234 WP11 Buttweld Fittings Radius

ASME SA 234 WP11 Buttweld Fittings Radius

  • 2D
  • 1D
  • 3D
  • 5D
Chrome Moly WP11 Weld Fittings Origin

Chrome Moly WP11 Weld Fittings Origin

  • Janpanese
  • European
  • Russia
  • American
ASTM A234 Gr WP11 Pipe Fittings Services

ASTM A234 Gr WP11 Pipe Fittings Services

  • Cutting
  • Shearing
  • Heat Treatment
Chromium-Molybdenum Steel WP11 Elbow Packaging

Chromium-Molybdenum Steel WP11 Elbow Packaging

  • Bundled
  • Wooden Box
  • Bubble Wraps
ASME SA234 Alloy Steel WP11 Tee Surface Finish

AASME SA234 Alloy Steel WP11 Tee Surface Finish

  • Polished
  • Pickled
CrMo A234 WP11 Reducer Testing

CrMo A234 WP11 Reducer Testing

  • PMI, Hardness test
  • Ultrasonic, HIC test

Top ASTM A234 WP11 Cl1 Tee and Elbow Supplier in Mumbai With Size 1/2 to 48” As Per ASME B16.9

CrMo A234 WP11 Reducer Size Chart

Are You Trying to Find the Best Deal on ASTM A234 WP11 Fittings? To get an estimate right away, send an email to kalpesh@manishasteelcentre.com.

O.D. or I.D. Diameter Nominal Diameter Typical Threads In Inch Equivalent Decimal

1-21/32

 1-1/4 11-1/2 1.660
1-29/32 1-1/2 11-1/2 1.900
2-3/8 2 11-1/2 2.375
2-7/8 2-1/2 8 2.875
4-1/2 4 8 4.500
1-3/64 3/4 14 1.050
1-5/16 1 11-1/2 1.315
3-1/2 3 8 3.500
4 3-1/2 8 4.000
5/16 1/16 27 0.313
13/32 1/8 27 0.405
35/64 1/4 18

0.540
43/64 3/8 18 0.675
27/32 1/2 14 0.840
Alloy Steel WP11 Pipe Bend Dimension
NPS (Normal Pipe Size) O.D. (Outside Daimeter) Return Elbow 180 Deg Elbow 90 Deg Elbow 45 Deg
(inch) Long Radius Elbow Long Radius Elbow Short Radius Long Radius Elbow
(inch./ Inches) (millimeter/ MM) Center to Center (.In) Back to face (.In) Center to Face (.In) Center to Face (.In) Center to Face (.In) Radius (.In)
3 3.500 88.9 9 6 1/4 4 1/2 3 2 6
3 1/2 4.000 101.6 10 1/2 7 1/4 5 1/4 3 1/2 2 1/4 7
4 4.500 114.3 12 8 1/4 6 4 2 1/2 8
2 2.375 60.3 6 4 3/16 3 2 1 3/8 4
5 5.563 141.3 15 10 5/16 7 1/2 5 3 1/8 10
6 6.625 168.3 18 12 5/16 9 6 3 3/4 12
1/2 0.840 21.3 2 1 7/8 1 1/2 – 5/8
3/4 1.050 26.7 2 1/4 1 11/16 1 1/8 – 7/16
12 12.750 323.9 36 24 3/8 18 12 7 1/2 18
2 1/2 2.875 73.0 7 1/2 5 3/16 3 3/4 2 1/2 1 3/4 5
8 8.625 219.1 24 16 5/16 12 8 5 12
1 1.315 33.4 3 2 3/16 1 1/2 1 7/8
1 1/4 1.660 42.2 3 3/4 2 3/4 1 7/8 1 1/4 1
1 1/2 1.900 48.3 4 1/2 3 1/4 2 1/4 1 1/2 1 1/8 3

Delivering the Best Quality Chrome Moly WP11 Cap and Reducer With Pressure Class 150 to 2500

ASTM A234 WP11 C12 Weld Fittings Pressure Rating
Temperature Ratings Pressure Class
150 300
1/4 - 1 Inches 1 1/4 - 2 Inches 2 1/2 - 3 Inches
(oF) (oC)
450 232 - 725 600 475
500 260 - 510 450 385
350 177 150 1150 900 650
400 204 - 935 750 560
-20 to 150 -29 to 66 300 2000 1500 1000
200 93 265 1785 1350 910
550 288 - 300 300 300
250 121 225 1575 1200 825
300 149 185 1360 1050 735
SA234 WP11 Elbow Tensile Strength
Tensile Strength, (minimum) ksi[MPa]
WP11 CL2 Fittings 70[485]
WP11 CL3 Fittings 75[520]
WP11 CL1 Fittings 60[415]
SA 234 Grade WP11 BW Fittings Tolerance Chart
Tolerance 90 Deg And 45 Deg Elbows And Pipe Tee Reducer & Lap Joint Stub End (Long / Short) Pipe End Caps
NPS OD at Bevel ID at End Center-to-End Dimension A ,C ,B Over-all Length Of H Over-all Length Of F
26 to 30 +0.25 +/- 0.19 +/- 0.12 +/- 0.19 +/- 0.38
- -0.19 - - - -
32 to 48 +0.25 +/- 0.19 +/- 0.19 +/- 0.19 +/- 0.38
- -0.19 - - - -
5 to 8 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.25
10 to 18 +0.16 +/- 0.12 +/- 0.09 +/- 0.09 +/- 0.25
- -0.12 - - - -
1/2 to 2-1/2 +0.06 - +/- 0.06 +/- 0.06 +/- 0.12
- -0.03 - - - -
3 to 3-1/2 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.12
4 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.12
20 to 24 +0.25 +/- 0.19 +/- 0.09 +/- 0.09 +/- 0.25
- -0.19 - - - -
ASME SA 234 WP11 Buttweld Fittings Wall Thickness
Normal Size Of Pipe (DN) Schedule Number Outer Daimeter In inch millmeter Wall Thickness inch millmeter Mass lb/ft kg/m
1 25 5S 1.315 33.4 0.065 1.65 0.68 1.02
1-1/4 32 5S 1.660 42.2 0.065 1.65 1.11 1.65
1-1/2 40 5S 1.900 48.3 0.065 1.65 1.28 1.90
2 50 5S 2.375 60.3 0.065 1.65 1.61 2.39
2-1/2 65 5S 2.875 73 0.083 2.11 2.48 3.69
5 125 5S 5.563 141.3 0.109 2.77 6.36 9.46
6 150 5S 6.625 168.3 0.109 2.77 7.59 11.31
1/2 15 5S 0.840 21.3 0.065 1.65 0.54 0.80
1/2 15 80S 0.840 21.3 0.147 3.73 1.09 1.62
3/4 20 80S 1.050 26.7 0.154 3.91 1.48 2.20
3 80 5S 3.500 88.9 0.083 2.11 3.03 4.52
3-1/2 90 5S 4.000 101.6 0.083 2.11 3.48 5.18
4 100 5S 4.500 114.3 0.083 2.11 3.92 5.84
1/8 6 5S 0.405 10.3 ... ...
1/4 8 10S 0.540 13.7 0.065 1.65 0.33 0.49
3/8 10 5S 0.675 17.1 ... ...
3/8 10 80S 0.675 17.1 0.126 3.20 0.74 1.10
Chrome Moly WP11 Weld Fittings Tee Weight
NPS Of ASME B16.9 Tee SS Tees Fitting Weight In (KG) Kilogram
22 187.79
24 239.5
12 54.43
14 74.84
1 0.34
1.1/4 0.59
1.1/2 0.91
26 349.27
30 480.81
36 675.85
1/2 0.16
3/4 0.2
8 24.95
10 38.56
16 88.45
18 112.94
2 1.59
2.1/2 2.72
3 3.18
3.1/2 4.08
4 5.44
5 9.53
6 15.42
20 155.13
Most Common Types Of WP11 Welded Pipe Fittings

Trusted ASTM A234 WP11 Fittings Supplier in India in Custom Shapes and Types

ASTM A234 WP11 Fittings Stub End

ASTM A234 WP11 Fittings Stub End

ASTM A234 WP11 C12 Pipe Bend

ASTM A234 WP11 C12 Pipe Bend

ASTM A234 WP11 C11 Cross

ASTM A234 WP11 C11 Cross

ASTM A234 Gr WP11 C11 Cap

ASTM A234 Gr WP11 C11 Cap

ASTM A234 Grade WP11 Class 1 Reducer

ASTM A234 Grade WP11 Class 1 Reducer

ASTM A234 Gr. WP11 C1.1 Tee

ASTM A234 Gr. WP11 C1.1 Tee

ASME SA 234 WP11 Elbow

ASME SA 234 WP11 Elbow

Chrome Moly WP11 Weldable Pipe Fittings

Chrome Moly WP11 Weldable Pipe Fittings

ASTM A234 Gr WP11 Seamless Pipe Fittings

ASTM A234 Gr WP11 Seamless Pipe Fittings

Specialize in Manufacturing Alloy Steel WP11 Seamless and Welded Pipe Fittings in Different Schedule
Alloy Steel ASTM A234 WP11 Cap Schedule Chart
DN Schedule 80S Schedule 40S Schedule 10S
900 Elbow 450 Elbow Equal tee 900 Elbow 450 Elbow Equal tee 900 Elbow 450 Elbow Equal tee
65 1.81 0.99 3.13 1.40 0.77 2.19 0.85 0.48 1.41
100 6.18 2.81 7.71 4.47 2.09 5.27 2.10 1.08 3.46
150 16.32 8.16 13.61 10.89 5.44 10.99 5.45 2.72 8.07
8 0.04 0.03 0.07 0.03 0.02 0.06 0.02 0.01 0.03
80 2.97 1.50 4.45 2.20 1.08 3.31 1.25 0.63 1.77
90 4.00 2.00 5.44 2.83 1.42 4.08 1.70 0.75 2.67
10 0.06 0.04 0.09 0.03 0.02 0.03 0.03 0.02 0.05
200 33.11 16.56 28.12 21.54 10.77 20.91 10.20 5.33 15.65
25 0.22 0.14 0.38 0.15 0.11 0.29 0.14 0.08 0.28
32 0.40 0.23 0.68 0.26 0.17 0.59 0.23 0.11 0.49
250 51.71 25.86 49.90 38.56 19.27 35.38 18.15 9.75 26.46
40 0.51 0.29 1.02 0.40 0.23 0.86 0.30 0.17 0.68
50 0.91 0.59 1.59 0.70 0.4 1.28 0.50 0.25 0.85
300 79.38 39.69 83.91 59.42 29.71 62.14 25.80 13.62 39.46
15 0.10 0.05 0.14 0.08 0.04 0.10 0.06 0.03 0.09
20 0.11 0.05 0.20 0.08 0.04 0.17 0.07 0.03 0.13
Stock and Supply ASTM A234 Gr WP11 Stub End and Cross For Moderate and High Temperature Services
WP11 Alloy Steel Stub End Mechanical Properties
h
Grade Elongation % Tensile Strength (Mpa) Yield Strength (Mpa)
A234 WP11 ≥20415 - 585 ≥205
Chromium-Molybdenum Steel WP11 Elbow Chemical Composition
Grade Cr Mo C Mn S Si P
WP11 Class1 1-1.5 0.44-0.65 0.05-0.15 0.3-0.6 ≤0.03 0.5-1 ≤0.03
WP11 Class2 1-1.5 0.44-0.65 0.05-0.2 0.3-0.8 ≤0.04 0.5-1 ≤0.04
ASTM A234 WP11 Fittings Delivery Time As Per Location
Changes in Price
Extra 5 %
Export to Shipping Time in Days
Argentina  45
Maldives  7
Colombia  45
Brazil  45-60
Taiwan  15
Cambodia  9
Chile  45
Venezuela  45
South Korea  7
Ecuador  60
Japan  7
Sri Lanka  5
Bolivia  45
Bangladesh  14
Mayanmar  25
