Inconel 600 Pipe Fittings | ASTM B366 WPNCI Buttweld Elbow/Tee

Best Quality ASTM B366 WPNCI Buttweld Fittings Manufacturer in India As Per ANSI B16.9

Table of Content

Inconel 600 Pipe Fittings Specification
Size Chart of Inconel 600 WPNCl Elbow
ASME Sb366 N06600 Butt Welded Fittings Dimensions
Pressure Rating of UNS N06600 Butt Welded Joint
DIN 2.4816 Welded Fittings Stock Range
Most Common Types Of Inconel 600 Pipe Fittings
ASTM B366 UNS N06600 Weld Fittings Schedule Chart
Tolerances of ASME SB 366 UNS N06600 Buttweld Fittings
600 Alloy Buttweld Pipe Fittings Equivalent Material
Chemical Composition of 2.4816 Inconel 600 Fittings
Ni 600 Butt Weld Fittings Mechanical Properties
Physical Properties of WPNCl-s Bw Fittings

Inconel 600 Pipe Fittings Specification

Genuine Inconel 600 Pipe Fittings Manufacturer in India As Per Specification

Nickel 600 Weldable Pipe Fittings Sizes

Welded Fittings: 1/2 to 48 in.
Seamless Fittings: 1/2" to 10" NB
Schedule : SCH 10 to 160
End : Plain Bevel, Compound Bevel, Buttweld, Bevelled

UNS N06600 Butt Welded Joint Manufacturing Standards

MSS-SP-43
ANSI B16.9
ASME B16.28
100% Tested With MTC EN 10204/3.1

B366 Gr.wpncl Butt Welding Fittings Physical Properties

Melting Point:1413°C
Density:8.47 g/cm³
Heat Treatment: 982°C

ASME Sb366 N06600 Butt Welded Fittings Process

Seamless
Fabricated
Welded

NCF 600 Seamless Pipe Fittings Types

Tee
Elbow
Cap
Reducer
Cross
Stub End

600 Nickel Alloy Welded Pipe Fittings International Standards

UNS: N06600
ASTM B366
WNR:2.4816
ANSI B16.9, MSS-SP-43, B16.28, ASME 16.11

DIN 2.4816 Welded Fittings Bending Radius

ASTM B366 UNS N06600 Weld Fittings Origin

European
Janpanese
Russia
American

Ni 600 Butt Weld Fittings Services

Shearing
Heat Treatment
Cutting

2.4816 Inconel 600 Fittings Packaging

Bubble Wraps
Bundled
Wooden Box

WPNCl-s Bw Fittings Surface Finish

Pickled
Polished

600 Alloy Buttweld Pipe Fittings Testing

PMI, Hardness test
Ultrasonic, HIC test

Supplier Of WNR 2.4816 Elbow and Reducer With Size Ranging From 1/2 - 10" (seamless) and 1/2 - 48" (welded)

Size Chart of Inconel 600 WPNCl Elbow

NPS (in.)	OD		Tee (Straight)	Cap	End			Cross (Straight)
NPS (in.)	(in.)	(mm)	Center - End (in.)	Length (in.)	Short Length (in.)	Lap Diameter (in.)	Long Length (in.)	Center - End (in.)
12	12.750	323.9	10	6	6	15	10	10
10	10.750	273.1	8 1/2	5	5	12 3/4	10	8 1/2
8	8.625	219.1	7	4	4	10 5/8	8	7
6	6.625	168.3	5 5/8	3 1/2	3 1/2	8 1/2	8	5 5/8
5	5.563	141.3	4 7/8	3	3	7 5/16	8	4 7/8
4	4.500	114.3	4 1/8	2 1/2	3	6 3/16	6	4 1/8
3 1/2	4.000	101.6	3 3/4	2 1/2	3	5 1/2	6	3 3/4
3	3.500	88.9	3 3/8	2	2 1/2	5	6	3 3/8
2 1/2	2.875	73.0	3	1 1/2	2 1/2	4 1/8	6	3
2	2.375	60.3	2 1/2	1 1/2	2 1/2	3 5/8	6	2 1/2
1 1/2	1.900	48.3	2 1/4	1 1/2	2	2 7/8	4	2 1/4
1 1/4	1.660	42.2	1 7/8	1 1/2	2	2 1/2	4	1 7/8
1	1.315	33.4	1 1/2	1 1/2	2	2	4	1 1/2
3/4	1.050	26.7	1 1/8	1	2	1 11/16	3	-
1/2	0.840	21.3	1	1	2	1 3/8	3	-

ASME Sb366 N06600 Butt Welded Fittings Dimensions

Are You Looking for the Best Price on Inconel 600 Pipe? If you would like an estimate immediately, send an email to kalpesh@manishasteelcentre.com.

Size	O.D		Return Elbow 180°		Elbow 45°		Elbow 90°
-	-		Long Radius Elbow		Long Radius Elbow		Long Radius Elbow	Short Radius
in.	mm	in.	Back - face (in.)	Center - Center (in.)	Radius (in.)	Center - Face (in.)	Center - Face (in.)	Center - Face (in.)
10	273.1	10.750	20 3/8	30	15	6 1/4	10	15
8	219.1	8.625	16 5/16	24	12	5	8	12
6	168.3	6.625	12 5/16	18	12	3 3/4	6	9
5	141.3	5.563	10 5/16	15	10	3 1/8	5	7 1/2
4	114.3	4.500	8 1/4	12	8	2 1/2	4	6
3 1/2	101.6	4.000	7 1/4	10 1/2	7	2 1/4	3 1/2	5 1/4
3	88.9	3.500	6 1/4	9	6	2	3	4 1/2
2 1/2	73.0	2.875	5 3/16	7 1/2	5	1 3/4	2 1/2	3 3/4
2	60.3	2.375	4 3/16	6	4	1 3/8	2	3
1 1/2	48.3	1.900	3 1/4	4 1/2	3	1 1/8	1 1/2	2 1/4
1 1/4	42.2	1.660	2 3/4	3 3/4		1	1 1/4	1 7/8
1	33.4	1.315	2 3/16	3		7/8	1	1 1/2
3/4	26.7	1.050	1 11/16	2 1/4		7/16	–	1 1/8
1/2	21.3	0.840	1 7/8	2		5/8	–	1 1/2

Manufacturing All Types of ASME SB 366 UNS N06600 Tee and Cap At Lowest Price to Handle Over Pressure

Pressure Rating of UNS N06600 Butt Welded Joint

Temperature		Pressure Class
		150	300
			1/4 - 1 (in.).	1 1/4 - 2 (in.).	2 1/2 - 3 (in.).
(°F)	(°C)		1/4 - 1 (in.).	1 1/4 - 2 (in.).	2 1/2 - 3 (in.).
550	288	-	300	300	300
500	260	-	510	450	385
450	232	-	725	600	475
400	204	-	935	750	560
350	177	150	1150	900	650
300	149	185	1360	1050	735
250	121	225	1575	1200	825
200	93	265	1785	1350	910
-20 - 150	-29 - 66	300	2000	1500	1000

Carries a Wide Range of Mandrel and Hot forming Made Nickel Alloy 600 Stub End and Cross Stock For Sale

DIN 2.4816 Welded Fittings Stock Range

Types	Seamless	Welded
Elbows	Upto 24"	Upto 42"
End Caps	Upto 24"	-
Cross	Upto 8"	Upto 36"
Return Bends	Upto 8"	-
Tees	Upto 24"	Upto 36"
Swage Nipple	Upto 4"	-
Reducers	Upto 24"	Upto 48"

Most Common Types Of Inconel 600 Pipe Fittings

Trusted Inconel 600 Pipe Fittings Supplier in India in Custom Shapes and Types

Inconel 600 WPNCl Elbow

Inconel 600 Tee

ASTM B366 WPNCl Fittings Reducer

B366 Gr.WPNCl Cap

ASTM B366 WPNCl Stub End

ASTM B366 Grade WPNCl Pipe Bend

ASTM B366 UNS N06600 Cross

Inconel 600 WPNCl Elbow Lr 90degree Bw

Inconel 600 Long Radius Reducing Elbow

B366 Gr.WPNCl Seamless Equal Tee

ASTM B366 WPNCl Tee Reducing Bw

ASTM B366 Grade WPNCl Long Pattern Stub End

Offer Premium Quality Ni 600 Seamless and Welded Pipe Fittings Online With Sch 10 To Sch 160

ASTM B366 UNS N06600 Weld Fittings Schedule Chart

Size	SCH 10S			SCH 40S			SCH 80S
Size	Elbow 90 Deg	B16.9 Equal Tee	Elbow 45 Deg	Elbow 90 Deg	B16.9 Equal Tee	Elbow 45 Deg	Elbow 90 Deg	B16.9 Equal Tee	Elbow 45 Deg
200	10.20	15.65	5.33	21.54	20.91	10.77	33.11	28.12	16.56
100	2.10	3.46	1.08	4.47	5.27	2.09	6.18	7.71	2.81
90	1.70	2.67	0.75	2.83	4.08	1.42	4.00	5.44	2.00
80	1.25	1.77	0.63	2.20	3.31	1.08	2.97	4.45	1.50
65	0.85	1.41	0.48	1.40	2.19	0.77	1.81	3.13	0.99
50	0.50	0.85	0.25	0.70	1.28	0.4	0.91	1.59	0.59
40	0.30	0.68	0.17	0.40	0.86	0.23	0.51	1.02	0.29
32	0.23	0.49	0.11	0.26	0.59	0.17	0.40	0.68	0.23
25	0.14	0.28	0.08	0.15	0.29	0.11	0.22	0.38	0.14
20	0.07	0.13	0.03	0.08	0.17	0.04	0.11	0.20	0.05
10	0.03	0.05	0.02	0.03	0.03	0.02	0.06	0.09	0.04

Tolerances of ASME SB 366 UNS N06600 Buttweld Fittings

Size	5 to 8	4	3 to 3½	1/2 to 2½
OD at Bevel	+ 2.04 - 1.06	1.06	1.06	+ 1.06 - 0.08
Center to End LR	2	2	2	2
OD at Bevel	+ 6.04 - 4.08	+ 6.04 - 4.08	+ 6.04 - 4.08	+ 4 - 3.02
Nominal Pipe Size	32 to 48	26 to 30	20 to 24	10 to 18
WT	Not less than 87.05%
Center to End 3D	6	6	3	3
ID at End	+ 6.04 - 4.08	+ 6.04 - 4.08	4.08	3.02
Center to End LR	5	3	2	2
Center to End 3D	3	3	3	3
ID at End	1.06	1.06	1.06	0.08

600 Alloy Buttweld Pipe Fittings Equivalent Material

Grade	UNS No.	WERKSTOFF NR.	JIS	GOST	BS	EN	AFNOR
Inconel 600	N06600	2.4816	NCF 600	МНЖМц 28-2,5-1,5	NA 13	NiCr15Fe	NC15FE11M

Chemical Composition of 2.4816 Inconel 600 Fittings

Grade	Manganese	Carbon	Silicon	Copper	Sulfur	Iron	Chromium	Nickel
Inconel 600	1.00 max	0.15 max	0.50 max	0.50 max	0.015max	6.00 – 10.00	14.00 – 17.00	72.00 min

Ni 600 Butt Weld Fittings Mechanical Properties

Element	Tensile Stress	Elongation	Yield Strength
Inconel 600	Psi – 95,000 , MPa – 655	40 %	Psi – 45,000 , MPa – 310

Physical Properties of WPNCl-s Bw Fittings

Element	Melting Point	Density
Inconel 600	1413 °C (2580 °F)	8.47 g/cm3

Inconel 600 Pipe Fittings Delivery Time As Per Location

Export to	Shipping Time in Days
Uk	30
Germany	21
Greece	45
Belgium	40
Portugal	45
Denmark	35
Italy	28
Russia	20
Czech Republic	45
