ASTM A234 WP5 Fittings Specification
ASTM A234 Grade WP5 Pipe Fittings Size Chart
Alloy Steel WP5 Pipe Bend Weight Chart
WP5 Welded Pipe Fittings Tolerances Chart
SA234 WP5 Seamless Pipe Fittings Heat Treatments
SA 234 Grade WP5 BW Fittings Application
Chrome Moly WP5 Weld Fittings Price List
Most Common Types Of ASTM A234 Gr WP5 Pipe Fittings
CrMo A234 WP5 Reducer Dimensions
ASME SA 234 WP5 Buttweld Fittings Pressure Rating
Alloy Steel ASTM A234 WP5 Cap Mechanical Properties
WP5 Alloy Steel Stub End Chemical Composition

ASTM A234 WP5 Fittings Specification

ASTM A234 Grade WP5 Pipe Fittings Sizes

Size : 1/8” NB TO 48” NB.
Schedule : 10 - 160
End :Plain Bevel,Buttweld, Bevelled ,Compound Bevel

ASME SA 234 WP5 Buttweld Fittings Manufacturing Standards

ASME SA234
ASTM A234

Chrome Moly WP5 Weld Fittings Benefits

Durability
corrosion resistance
high strength

ASTM A234 Gr WP5 Pipe Fittings Process

Casting
forging
Hot forming
Cold forming

Chromium-Molybdenum Steel WP5 Elbow Types

Elbow , Tee
Stub End , Pipe Bend
Reducer , Cap , Cross

ASME SA234 Alloy Steel WP5 Tee International Standards

ASME/ANSI B16.9
ASME B16.28
ASME SA234

ASME SA234 Alloy Steel WP5 Tee Bending Radius

CrMo A234 WP5 Reducer Origin

European
Janpanese
Russia
American

Alloy Steel ASTM A234 WP5 Cap Services

Cutting
Shearing
Heat Treatment

WP5 Alloy Steel Stub End Packaging

Bundled
Wooden Box
Bubble Wraps

Alloy Steel WP5 Pipe Bend Surface Finish

Polished
Pickled

ASTM A234 WP5 Alloy Steel Cross Testing

PMI, Hardness test
Ultrasonic, HIC test

Best Chrome Moly WP5 Buttweld Pipe Fittings Supplier in Mumbai in Odd Size

ASTM A234 Grade WP5 Pipe Fittings Size Chart

Are You Trying to Find the Best Deal on ASTM A234 WP5 Fittings? To get an estimate right away, send an email to kalpesh@manishasteelcentre.com.

O.D. or I.D. Diameter	Nominal Diameter	Typical Threads In Inch	Equivalent Decimal
2-7/8	2-1/2	8	2.875
3-1/2	3	8	3.500
4	3-1/2	8	4.000
4-1/2	4	8	4.500
43/64	3/8	18	0.675
27/32	1/2	14	0.840
1-3/64	3/4	14	1.050
1-5/16	1	11-1/2	1.315
5/16	1/16	27	0.313
13/32	1/8	27	0.405
35/64	1/4	18	0.540
1-21/32	1-1/4	11-1/2	1.660
1-29/32	1-1/2	11-1/2	1.900
2-3/8	2	11-1/2	2.375

Get Ready Stock Of Hot and Mandrel Alloy Steel WP5 Tee and Cap Online For Sale

Alloy Steel WP5 Pipe Bend Weight Chart

DN (Normal Pipe Size) For ASME B16.9	Schedule 10S			Schedule 40S			Schedule 80S
DN (Normal Pipe Size) For ASME B16.9	Elbow 90 Deg	Elbow 45 Deg	B16.9 Equal Tee	Elbow 90 Deg	Elbow 45 Deg	B16.9 Equal Tee	Elbow 90 Deg	Elbow 45 Deg	B16.9 Equal Tee
50	0.50	0.25	0.85	0.70	0.4	1.28	0.91	0.59	1.59
90	1.70	0.75	2.67	2.83	1.42	4.08	4.00	2.00	5.44
150	5.45	2.72	8.07	10.89	5.44	10.99	16.32	8.16	13.61
200	10.20	5.33	15.65	21.54	10.77	20.91	33.11	16.56	28.12
250	18.15	9.75	26.46	38.56	19.27	35.38	51.71	25.86	49.90
32	0.23	0.11	0.49	0.26	0.17	0.59	0.40	0.23	0.68
40	0.30	0.17	0.68	0.40	0.23	0.86	0.51	0.29	1.02
300	25.80	13.62	39.46	59.42	29.71	62.14	79.38	39.69	83.91
65	0.85	0.48	1.41	1.40	0.77	2.19	1.81	0.99	3.13
80	1.25	0.63	1.77	2.20	1.08	3.31	2.97	1.50	4.45
100	2.10	1.08	3.46	4.47	2.09	5.27	6.18	2.81	7.71
8	0.02	0.01	0.03	0.03	0.02	0.06	0.04	0.03	0.07
10	0.03	0.02	0.05	0.03	0.02	0.03	0.06	0.04	0.09
15	0.06	0.03	0.09	0.08	0.04	0.10	0.10	0.05	0.14
20	0.07	0.03	0.13	0.08	0.04	0.17	0.11	0.05	0.20
25	0.14	0.08	0.28	0.15	0.11	0.29	0.22	0.14	0.38

WP5 Welded Pipe Fittings Tolerances Chart

STM A234 WP5 Pipe Fittings (Grade WP5 To WP91) Tolerance>			90 Deg And 45 Deg> Elbows And Pipe Tee	Pipe End Caps	Reducer (Concentric/ Eccentric) & Lap Joint Stub End (Long / Short)
Normal Pipe Size (NPS) Of ASME B16.9	O. (Outside) D. (Daimeter) at Bevel	I. (Inside) D.(Daimeter) at End	Center-to-End Dimension A ,C ,B	Over-all Length Of F	Over-all Length Of H	Wall Thickness Of T
1/2 to 2-1/2	+0.06		+/- 0.06	+/- 0.12	+/- 0.06	1/2 to 2-1/2
	-0.03
3 to 3-1/2	+/- 0.06	+/- 0.06	+/- 0.06	+/- 0.12	+/- 0.06

4	+/- 0.06	+/- 0.06	+/- 0.06	+/- 0.12	+/- 0.06

5 to 8	+/- 0.06	+/- 0.06	+/- 0.06	+/- 0.25	+/- 0.06

10 to 18	+0.16	+/- 0.12	+/- 0.09	+/- 0.25	+/- 0.09
	-0.12
20 to 24	+0.25	+/- 0.19	+/- 0.09	+/- 0.25	+/- 0.09
	-0.19
26 to 30	+0.25	+/- 0.19	+/- 0.12	+/- 0.38	+/- 0.19
	-0.19
32 to 48	+0.25	+/- 0.19	+/- 0.19	+/- 0.38	+/- 0.19
	-0.19

SA234 WP5 Seamless Pipe Fittings Heat Treatments

Tempering Temperature	Minimum Austenitizing Temperature
Not be less than 675°C [1250°F]	955°C [1750°F]

SA 234 Grade WP5 BW Fittings Application

Oil And Gas Industry
Dairy And Food Processing
Modern Architecture
Fluid Piping
Pharmaceutical Processing Industry
Pulp And Paper Industry
Stub End For Power Plants
Heat Exchanger

Chrome Moly WP5 Weld Fittings Price List

For Updated ASTM A234 WP5 Fittings Price List. Directly Contact Us and Obtain a Quote Right Away

Wall Thickness	Size	Price USD/ Pcs	Type
0.179″	1	US $31.50	Seamless
0.191″	1 1/4	US $26.72	Seamless
0.147″	1/2	US $65.29	Seamless
0.154″	3/4	US $61.91	Seamless

Most Common Types Of ASTM A234 Gr WP5 Pipe Fittings

Trusted ASTM A234 WP5 Fittings Supplier in India in Custom Shapes and Types

ASTM A234 WP5 Stub End

ASTM A234 WP5 Pipe Bend

ASTM A234 WP5 Cross

Chrome Moly WP5 Cap

Chrome Moly WP5 Reducer

Chromium-Molybdenum Steel WP5 Tee

ASME SA234 Alloy Steel WP5 Elbow

CrMo A234 WP5 Weldable Pipe Fittings

Alloy Steel ASTM A234 WP5 Seamless Pipe Fittings

Buy Superior WP5 Alloy Steel Stub End and Cross in Various Schedule and Pressure Rating At Lowest Possible Price

CrMo A234 WP5 Reducer Dimensions

NPS (Normal Pipe Size)	O.D. (Outside Daimeter)		Elbow 90 Deg		Elbow 45 Deg		Return Elbow 180 Deg
(inch)			Long Radius Elbow	Short Radius	Long Radius Elbow		Long Radius Elbow
	(millimeter/ MM)	(inch./ Inches)	Center to Face (Inches)	Center to Face (Inches)	Center to Face (Inches)	Radius (Inches)	Center to Center (Inches)	Back to face (Inches)
1 1/2	48.3	1.900	2 1/4	1 1/2	1 1/8	3	4 1/2	3 1/4
2	60.3	2.375	3	2	1 3/8	4	6	4 3/16
2 1/2	73.0	2.875	3 3/4	2 1/2	1 3/4	5	7 1/2	5 3/16
5	141.3	5.563	7 1/2	5	3 1/8	10	15	10 5/16
6	168.3	6.625	9	6	3 3/4	12	18	12 5/16
8	219.1	8.625	12	8	5	12	24	16 5/16
1/2	21.3	0.840	1 1/2	–	5/8		2	1 7/8
3/4	26.7	1.050	1 1/8	–	7/16		2 1/4	1 11/16
1	33.4	1.315	1 1/2	1	7/8		3	2 3/16
1 1/4	42.2	1.660	1 7/8	1 1/4	1		3 3/4	2 3/4
10	273.1	10.750	15	10	6 1/4	15	30	20 3/8
12	323.9	12.750	18	12	7 1/2	18	36	24 3/8
3	88.9	3.500	4 1/2	3	2	6	9	6 1/4
3 1/2	101.6	4.000	5 1/4	3 1/2	2 1/4	7	10 1/2	7 1/4
4	114.3	4.500	6	4	2 1/2	8	12	8 1/4

Offer Chromium-Molybdenum Steel WP5 Weld Fittings Most Suitable For High Pressure Conditions

ASME SA 234 WP5 Buttweld Fittings Pressure Rating

Temperature Ratings		Pressure Class
		150	300
			1/4 - 1 Inches	1 1/4 - 2 Inches	2 1/2 - 3 Inches
(oF)	(oC)		1/4 - 1 Inches	1 1/4 - 2 Inches	2 1/2 - 3 Inches
350	177	150	1150	900	650
400	204	-	935	750	560
450	232	-	725	600	475
550	288	-	300	300	300
500	260	-	510	450	385
-20 to 150	-29 to 66	300	2000	1500	1000
200	93	265	1785	1350	910
250	121	225	1575	1200	825
300	149	185	1360	1050	735

Alloy Steel ASTM A234 WP5 Cap Mechanical Properties

Grade	Yield Strength (Mpa)	Elongation %	Tensile Strength (Mpa)
ASTM A234 WP5 Pipe Fittings	≥205	≥20	415 - 585

WP5 Alloy Steel Stub End Chemical Composition

Gr	Si	Cr	Mo	S	C	Mn	P
ASTM A234 WP5 Pipe Fittings	≤0.5	4-6	0.44-0.65	≤0.04	≤0.15	≤0.6	≤0.03

ASTM A234 WP5 Fittings Delivery Time As Per Location

Changes in Price Extra 5 %
Export to	Shipping Time in Days
Argentina	45
Maldives	7
Colombia	45
Brazil	45-60
Taiwan	15
Cambodia	9
Chile	45
Venezuela	45
South Korea	7
Ecuador	60
Japan	7
Sri Lanka	5
Bolivia	45
Bangladesh	14
Mayanmar	25
