Are You Looking for ASTM A815 UNS S31803 Fittings at the Best Price? In order to obtain an estimate immediately, send an email to kalpesh@manishasteelcentre.com.
| Size | Price in USD/piece |
|---|---|
| 10" x Sch 40 | US $19.56 |
| 8" x Sch 40 | US $15.54 |
| 6" x Sch 40 | US $10.36 |
| 4" x Sch 40 | US $8.29 |
| 3" x Sch 40 | US $5.64 |
| 2" x Sch 40 | US $42.59 |
| Size | All Fittings | All Fittings | Elbows And Tees | 180 Deg Return Bends | Reducers | 180 Deg Return Bends | Caps | 180 Deg Return Bends |
|---|---|---|---|---|---|---|---|---|
| NPS | I.D | O.D | Centre - End Dimension | Centre - Centre | Overall Length | Back - Face | Overall Length | Ends Alignment |
| 32 - 48 | 0.19 | 0.25 - 0.19 | 0.19 | - | 0.19 | - | 0.38 | - |
| 26 - 30 | 0.25 - 0.19 | 0.12 | - | - | - | |||
| 20 - 24 | 0.25 - 0.19 | 0.09 | 0.38 | 0.09 | 0.25 | 0.25 | 0.06 | |
| 10 - 18 | 0.12 | 0.16 - 0.12 | ||||||
| 5 - 8 | 0.06 | 0.09 - 0.06 | 0.06 | 0.25 | 0.06 | 0.03 | ||
| 4 | 0.06 | 0.12 | ||||||
| 3 - 3 ½ | 0.06 | |||||||
| ½ - 2½ | 0.03 | 0.06 - 0.03 |
| DN | Size | Weight |
|---|---|---|
| 20 | 3/4 | 0.11 |
| 32 | 1 1/4 | 0.25 |
| 40 | 1 1/2 | 0.39 |
| 50 | 2 | 0.66 |
| 80 | 3 | 2.19 |
| 90 | 3 1/2 | 2.96 |
| 100 | 4 | 4.12 |
| 200 | 8 | 21.6 |
| 300 | 12 | 61 |
| 400 | 16 | 121 |
| 500 | 20 | 232 |
| 600 | 24 | 377 |
| Form | Size Range | |
|---|---|---|
| Seamless | Welded | |
| Tees | 1/8" to 24" NB | Upto 42" NB |
| End Caps | 1/8" to 24" NB | Upto 42" NB |
| Reducers | 1/8" to 24" NB | Upto 42" NB |
| Return Bends | 1/8" to 8" NB | - |
| Swage Nipple | 2 1/16" to 30" | |
| Cross | 1/8" to 8" NB | |
| Elbows — 45, 90 & 180 Degree | 1/8" to 24" NB | Upto 42" NB |
| Size | SCH 10S | SCH 40S | SCH 80S | ||||||
|---|---|---|---|---|---|---|---|---|---|
| Elbow 90° | B16.9 Equal Tee | Elbow 45° | Elbow 90° | B16.9 Equal Tee | Elbow 45° | Elbow 90° | B16.9 Equal Tee | Elbow 45° | |
| 100 | 2.10 | 3.46 | 1.08 | 4.47 | 5.27 | 2.09 | 6.18 | 7.71 | 2.81 |
| 90 | 1.70 | 2.67 | 0.75 | 2.83 | 4.08 | 1.42 | 4.00 | 5.44 | 2.00 |
| 80 | 1.25 | 1.77 | 0.63 | 2.20 | 3.31 | 1.08 | 2.97 | 4.45 | 1.50 |
| 65 | 0.85 | 1.41 | 0.48 | 1.40 | 2.19 | 0.77 | 1.81 | 3.13 | 0.99 |
| 50 | 0.50 | 0.85 | 0.25 | 0.70 | 1.28 | 0.4 | 0.91 | 1.59 | 0.59 |
| 40 | 0.30 | 0.68 | 0.17 | 0.40 | 0.86 | 0.23 | 0.51 | 1.02 | 0.29 |
| 32 | 0.23 | 0.49 | 0.11 | 0.26 | 0.59 | 0.17 | 0.40 | 0.68 | 0.23 |
| 25 | 0.14 | 0.28 | 0.08 | 0.15 | 0.29 | 0.11 | 0.22 | 0.38 | 0.14 |
| 20 | 0.07 | 0.13 | 0.03 | 0.08 | 0.17 | 0.04 | 0.11 | 0.20 | 0.05 |
| 15 | 0.06 | 0.09 | 0.03 | 0.08 | 0.10 | 0.04 | 0.10 | 0.14 | 0.05 |
| 10 | 0.03 | 0.05 | 0.02 | 0.03 | 0.03 | 0.02 | 0.06 | 0.09 | 0.04 |
Trusted ASTM A815 UNS S31803 Fittings Supplier in India in Custom Shapes and Types
SA 815 S31803 Welded Pipe Fittings
ASTM A815 S31803 Seamless Pipe Fittings
ASTM A815 UNS S31803 Elbow
ASME SA 815 UNS S31803 Tee
SA 815 UNS S31803 Reducer
ASTM A815 S31803 Cap
SA 815 S31803 Stub End
Duplex Steel UNS S31803 Pipe Bend
ASTM B815 Gr. UNS S31803 Cross
| Temperature | Pressure Class | ||||
|---|---|---|---|---|---|
| 150 | 300 | ||||
| 1/4 - 1 in. | 1 1/4 - 2 in. | 2 1/2 - 3 in. | |||
| (°F) | (°C) | ||||
| 550 | 288 | - | 300 | 300 | 300 |
| 500 | 260 | - | 510 | 450 | 385 |
| 450 | 232 | - | 725 | 600 | 475 |
| 400 | 204 | - | 935 | 750 | 560 |
| 350 | 177 | 150 | 1150 | 900 | 650 |
| 300 | 149 | 185 | 1360 | 1050 | 735 |
| 250 | 121 | 225 | 1575 | 1200 | 825 |
| 200 | 93 | 265 | 1785 | 1350 | 910 |
| Elements | Values |
|---|---|
| Silicon | ≤1 |
| Manganese | ≤2 |
| Phosphate | ≤0.03 |
| Chromium | 21 - 23 |
| Carbon | ≤0.03 |
| Sulfur | ≤0.02 |
| Nickel | 4.5 - 6.5 |
| Nitrogen | 0.08 - 0.2 |
| Molybdenum | 2.5 - 3.5 |
| Yield Strength | Elongation | Tensile Strength | Charpy V-Notch Impact | Rockwell | |
|---|---|---|---|---|---|
| ksi. (Mpa) | % | ksi.(Mpa) | mm-N/mm2 | mm-N/mm2 | Hardness |
| 90 (621) | 28 | 125 (862) | 1310 | 844 | 25C |
| Property | 300°C | 200°C | 100°C | 20°C | Units |
|---|---|---|---|---|---|
| Electric resistivity | 1 | 0.9 | 0.85 | 0.8 | µΩm |
| Density | - | - | - | 7.8 | g/cm³ |
| - | - | - | 0.28 | lb/in³ | |
| Thermal capacity | 590 | 560 | 530 | 500 | J/kg°C |
| Modulus of elasticity | 180 | 186 | 194 | 200 | GPa |
| - | - | - | 29 | psi x 10-6 | |
| Linear expansion (RT ➞ T)°C | 14 | 13.5 | 13 | - | x 10-6/°C |
| Poissons ratio | - | - | - | 0.3 | - |
| Thermal conductivity | 18 | 17 | 16 | 15 | W/m°C |
| Stainless Steel | UNS no. | Tradename | Density (g/cm3) | Werkstoff No. |
|---|---|---|---|---|
| Duplex | S31803 / S32205 | F51 / 2205, F60 | 7.805 | 1.4462 |
| Export to | Delivery Time in Days |
|---|---|
| South Africa | 25-30 |
| Indonesia | 9 |
| Saudi Arabia | 7 |
| Italy | 30 |
| Malaysia | 10 |
| Oman | 5 |
| Singapore | 8 |
| France | 30 |
