ASTM A105 Fittings | ASME SA 105N Forged Elbow/Nipple Dimension

Most Eminent Manufacturer Of ASME SA 105 Forged Fittings in India As Per MSS, ASME, API Standards

Table of Content

ASTM A105 Fittings Specification
Sa105 Seamless Pipe Fittings Size Chart
Dimensions Chart of A105 Stub End
Sa105 Seamless Pipe Fittings Weight Chart
Pressure Rating Chart of ASTM A105 Bushing
Most Common Types of ASTM A105 Welded Pipe Fittings
Testings of Sa105 Seamless Pipe Fittings
Difference Between ASTM A105 and A106 Material
Mechanical Properties of ASTM A105N Reducer
Chemical Composition of ASTM A105 Bushing
Applications of ASTM A105 Pipe Bend

ASTM A105 Fittings Specification

Astm A105 Elbow Sizes

Welded Fittings: 1/8" NB to 4" NB
Schedule : Schedule 80 TO Schedule XXS.
End : Plain Bevel, Compound Bevel, Buttweld, Bevelled

A105 Tee Manufacturing Standards

ASME 16.11
MSS SP-79,83, 95, 97
BS 3799

ASTM A105 Bushing Physical Properties

Melting Point: 1380 °C
Density:7.9 g/cm3
Electrical Resistivity: 720 (n.m)

ASTM A105 Pipe Bend Process

Seamless
Fabricated
Welded

Sa105 Cross Types

Elbow
Stub End
Pipe Bend

ASTM A105 Pipe Bend International Standards

UNS: K03504
ASME B16.11 | ASTM A105
WERKSTOFF NR.: 1.0460

Astm A105 Elbow Bending Radius

ASTM A105 Cap Origin

Russia
Janpanese
American
European

ASTM A105N Reducer Services

Shearing
Heat Treatment
Cutting

ASTM A105 Bushing Packaging

Bubble Wraps
Bundled
Wooden Box

ASTM A105 Welded Pipe Fittings Surface Finish

Pickled
Polished

Sa105 Seamless Pipe Fittings Testing

Ultrasonic, HIC test
PMI, Hardness test

Best Carbon Steel A105 Socket Weld and Threaded Fittings Supplier in Mumbai With Size 1/8 to 4" NB, Refer Dimensions

Sa105 Seamless Pipe Fittings Size Chart

Are You Trying to Find the Best Deal on ASTM A105 Fittings ? To get an estimate right away, send an email to kalpesh@manishasteelcentre.com.

DESCRIPTN OF ASTM A105 WELDED PIPE FITTINGS SIZE	CLASS DESIGNATION
DESCRIPTN OF ASTM A105 WELDED PIPE FITTINGS SIZE	CLASS 9000	CLASS 6000	CLASS 3000
ASME B16.11 CROSS ASME B16.11 UNION / ASME B16.11 CAP ELBOW (90 DEGREE & 45 DEGREE)	½ - 2 Inches	½ - 2 Inches	½ - 4 Inches
	½ - 2 Inches	½ - 2 Inches	½ - 4 Inches
	½ - 2 Inches	½ - 2 Inches	½ - 4 Inches

Dimensions Chart of A105 Stub End

NPS	MIN. WIDTH OF FLATS (F)	MIN. THEAD LENGTH (A)
1-1/4	1-3/4	13/16
4	4-5/8	1-1/4
1/4	5/8	7/16
3-1/2	4-1/8	1-3/16
1-1/2	2	13/16
1	1-3/8	3/4
3/8	11/16	1/2
3	3-1/2	1-1/8
1/2	7/8	9/16
2-1/2	3	1-1/16
3/4	1-1/16	5/8
2	2-1/2	7/8

Sa105 Seamless Pipe Fittings Weight Chart

NPS	End CAP			Half Coupling		90 Deg Elbow		Tee
NPS	3000#	2000 LBS	Class 6000	6000 LBS	3000 LBS	Class 3000	Class 2000	3000 LBS
11/4	0.36	0.70	1.14	0.52	0.36	0.76	0.50	1.06
3	1.60	4.53	7.38	3.00	1.60	4.92	3.24	6.88
1	0.21	0.43	0.72	0.44	0.21	0.48	0.31	0.67
3/8	0.03	0.09	0.18	0.09	0.03	0.12	0.07	0.16
21/2	1.15	2.84	4.62	2.00	1.15	3.08	2.03	4.31
1/2	0.07	0.16	0.28	0.16	0.07	0.19	0.12	0.26
2	0.69	1.77	2.89	1.40	0.69	1.93	1.27	2.70
3/4	0.10	0.26	0.45	0.22	0.10	0.30	0.19	0.42
11/2	0.52	1.10	1.81	0.95	0.52	1.21	0.79	1.69

Keep Wide Selection of ASTM A105N Elbow and Nipple Fittings Use in Pressure Systems For High Temperature Service At Fair Price

Pressure Rating Chart of ASTM A105 Bushing

Pressure	Schedule	Types of Connection
3000#	SCH 80	SOCKET WELD (SW)
6000#	SCH XXS	THREADED (NPT)
3000#	SCH 160	THREADED (NPT)
6000#	SCH 160	SOCKET WELD (SW)

One Stop Shop for SA 105 Buttweld Pipe Fittings in Various Types Tee, Reducer, Cap, Stub End etc. With Hydrostatic Tests

Most Common Types of ASTM A105 Welded Pipe Fittings

ASTM A105 Fittings Supplier In India Offering Custom Shapes And Types

ASTM A105 Elbow

A105 Stub End

ASTM A105 Pipe Bend

ASTM A105 Cap

SA105 Union

A105 Tee

ASTM A105 Bushing

SA105 Cross

ASTM A105N Reducer

Testings of Sa105 Seamless Pipe Fittings

Impact Testing
Hydrostatic Pressure Test
Dimensional Inspection
Chemical Composition
Visual Inspection
Non-Destructive Testing

Understand Difference Between ASTM A105 and A106 Material

Difference Between ASTM A105 and A106 Material

Properties	ASTM A105	ASTM A106
Carbon content	Max 0.35%	Varies by grade, from 0.25% to 0.35%
Manganese content	0.60–1.05%	0.27–0.93% for Grade A, 0.29–1.06% for Grades B and C
Applications	Used for pipe fittings	Used for high-temperature and high-pressure applications, such as machine parts

Mechanical Properties of ASTM A105N Reducer

ELONGATION IN 2IN, BASIC MIN WALL 5/16″ AND OVER, STRIP TEST	30%
TENSILE	70 ksi, min
HARDNESS	187 HBW max
YIELD	36 ksi, min

Chemical Composition of ASTM A105 Bushing

ELEMENT	COMPOSITION %, NOTE C
Silicon	.10-35
Vanadium	.08 MAX, (NOTE A)
Carbon	.35 MAX
Molybdenum	.12 MAX, (NOTE A,B)
Manganese	.60-1.05
Chromium	.30 MAX, (NOTE A,B)
Phosphorus	.035 MAX
Nickel	.40 MAX, (NOTE A)
Sulfur	.040 MAX
Copper	.40 MAX, (NOTE A)

Applications of ASTM A105 Pipe Bend

Power Generation
Food and Beverage Industry
Marine and Offshore
Chemical Processing Plants
Heat Exchanger Systems
Pharmaceutical Industries
Oil and Gas

ASTM A105 Fittings Shipping Time as per Location

Cost Variations 5 % extra
Export to	Shipping Time
Saudi Arabia	7
South Africa	25-30
Kuwait	10
Philippines	14
Belgium	40-60
Singapore	8
Italy	30
Amsterdam	30
France	30
UAE	5 days
Malaysia	10
Qatar	7
Germany	9
Oman	5
Bahrain	9
