Are You Trying to Find the Best Deal on ASTM A403 WP310 Fittings ? To get an estimate right away, send an email to kalpesh@manishasteelcentre.com.
| Heat Treatment Process | Temprature |
|---|---|
| Pickling / Passivation | Post-heat treatment surface treatment |
| Solution Annealing | 1010°C to 1120°C (1850°F to 2050°F) |
| Stress Relieving | 400°C to 600°C (750°F to 1100°F) |
| Rapid Cooling | Water quenching or air cooling |
| NPS | (O.D.) | 180 DEGREE RETURN | 45 DEGREE ELBOW | 90 DEGREE ELBOW | ||||
|---|---|---|---|---|---|---|---|---|
| (IN) | LONG RADIUS ELBOW | LONG RADIUS ELBOW | SHORT RADIUS | LONG RADIUS ELBOW | ||||
| (IN) | (MM) | BACK TO FACE(IN) | CENTER TO CENTER(IN) | RADIUS(IN) | CENTER TO FACE(IN) | CENTER TO FACE(IN) | CENTER TO FACE(IN) | |
| 3 | 3.500 | 88.9 | 6 1/4 | 9 | 6 | 2 | 3 | 4 1/2 |
| 12 | 12.750 | 323.9 | 24 3/8 | 36 | 18 | 7 1/2 | 12 | 18 |
| 3 1/2 | 4.000 | 101.6 | 7 1/4 | 10 1/2 | 7 | 2 1/4 | 3 1/2 | 5 1/4 |
| 1/2 | 0.840 | 21.3 | 1 7/8 | 2 | 5/8 | – | 1 1/2 | |
| 10 | 10.750 | 273.1 | 20 3/8 | 30 | 15 | 6 1/4 | 10 | 15 |
| 2 1/2 | 2.875 | 73.0 | 5 3/16 | 7 1/2 | 5 | 1 3/4 | 2 1/2 | 3 3/4 |
| 3/4 | 1.050 | 26.7 | 1 11/16 | 2 1/4 | 7/16 | – | 1 1/8 | |
| 8 | 8.625 | 219.1 | 16 5/16 | 24 | 12 | 5 | 8 | 12 |
| 1 | 1.315 | 33.4 | 2 3/16 | 3 | 7/8 | 1 | 1 1/2 | |
| 6 | 6.625 | 168.3 | 12 5/16 | 18 | 12 | 3 3/4 | 6 | 9 |
| 1 1/4 | 1.660 | 42.2 | 2 3/4 | 3 3/4 | 1 | 1 1/4 | 1 7/8 | |
| 5 | 5.563 | 141.3 | 10 5/16 | 15 | 10 | 3 1/8 | 5 | 7 1/2 |
| 1 1/2 | 1.900 | 48.3 | 3 1/4 | 4 1/2 | 3 | 1 1/8 | 1 1/2 | 2 1/4 |
| 4 | 4.500 | 114.3 | 8 1/4 | 12 | 8 | 2 1/2 | 4 | 6 |
| 2 | 2.375 | 60.3 | 4 3/16 | 6 | 4 | 1 3/8 | 2 | 3 |
| PRODUCT RANGES & THEORETICAL WEIGHTS IN (KG) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| DN | SCHEDULE (80S) | SCHEDULE (40S) | SCHEDULE (10S) | ||||||
| EQUAL TEE | 450 ELBOW | 900 ELBOW | EQUAL TEE | 450 ELBOW | 900 ELBOW | EQUAL TEE | 450 ELBOW | 900 ELBOW | |
| 50 | 1.59 | 0.59 | 0.91 | 1.28 | 0.4 | 0.70 | 0.85 | 0.25 | 0.50 |
| 300 | 83.91 | 39.69 | 79.38 | 62.14 | 29.71 | 59.42 | 39.46 | 13.62 | 25.80 |
| 40 | 1.02 | 0.29 | 0.51 | 0.86 | 0.23 | 0.40 | 0.68 | 0.17 | 0.30 |
| 8 | 0.07 | 0.03 | 0.04 | 0.06 | 0.02 | 0.03 | 0.03 | 0.01 | 0.02 |
| 250 | 49.90 | 25.86 | 51.71 | 35.38 | 19.27 | 38.56 | 26.46 | 9.75 | 18.15 |
| 65 | 3.13 | 0.99 | 1.81 | 2.19 | 0.77 | 1.40 | 1.41 | 0.48 | 0.85 |
| 10 | 0.09 | 0.04 | 0.06 | 0.03 | 0.02 | 0.03 | 0.05 | 0.02 | 0.03 |
| 200 | 28.12 | 16.56 | 33.11 | 20.91 | 10.77 | 21.54 | 15.65 | 5.33 | 10.20 |
| 15 | 0.14 | 0.05 | 0.10 | 0.10 | 0.04 | 0.08 | 0.09 | 0.03 | 0.06 |
| 150 | 13.61 | 8.16 | 16.32 | 10.99 | 5.44 | 10.89 | 8.07 | 2.72 | 5.45 |
| 20 | 0.20 | 0.05 | 0.11 | 0.17 | 0.04 | 0.08 | 0.13 | 0.03 | 0.07 |
| 100 | 7.71 | 2.81 | 6.18 | 5.27 | 2.09 | 4.47 | 3.46 | 1.08 | 2.10 |
| 25 | 0.38 | 0.14 | 0.22 | 0.29 | 0.11 | 0.15 | 0.28 | 0.08 | 0.14 |
| 90 | 5.44 | 2.00 | 4.00 | 4.08 | 1.42 | 2.83 | 2.67 | 0.75 | 1.70 |
| 32 | 0.68 | 0.23 | 0.40 | 0.59 | 0.17 | 0.26 | 0.49 | 0.11 | 0.23 |
| 80 | 4.45 | 1.50 | 2.97 | 3.31 | 1.08 | 2.20 | 1.77 | 0.63 | 1.25 |
| PRESSURE- RATINGS FOR ASTM A403 WP310 FITTINGS | |||||
|---|---|---|---|---|---|
| TEMPERATURE RATINGS | PRESSURE CLASS | ||||
| 150 | 300 | ||||
| 2 1/2 - 3 (IN). | 1 1/4 - 2 (IN). | 1/4 - 1 (IN). | |||
| (oC) | (oF) | ||||
| 177 | 350 | 150 | 650 | 900 | 1150 |
| 288 | 550 | - | 300 | 300 | 300 |
| 93 | 200 | 265 | 910 | 1350 | 1785 |
| 260 | 500 | - | 385 | 450 | 510 |
| 121 | 250 | 225 | 825 | 1200 | 1575 |
| 232 | 450 | - | 475 | 600 | 725 |
| 149 | 300 | 185 | 735 | 1050 | 1360 |
| 204 | 400 | - | 560 | 750 | 935 |
| -29 to 66 | -20 to 150 | 300 | 1000 | 1500 | 2000 |
ASTM A403 Wp310 Fittings Supplier In India With Custom Shapes And Types
ASTM A403 WP310 Fittings
310 Stainless Steel Pipe Fittings
ASME SA 403 WP310 Butt Weld Fittings
ASTM A403 Grade WP310 Tee
ASTM A403 Gr WP310 Reducer
A403 Gr WP310 Cross
ASTM A403 WP 310 Cap
A403 Gr WP310 fittings
ASTM A403 WP310 Elbow
| DENSITY IN (g/cm3) | TENSILE STRENGTH | ELONGATION | MELTING POINT | YIELD STRENGTH (0.2%OFFSET) |
|---|---|---|---|---|
| 7.9 | MPa – 515, Psi – 75000 | 40 % | 1402°C (2555 °F) | Psi – 30000 , MPa – 205 |
| GRADE | N | C | Ni | Mn | S | Si | Cr | P | |
|---|---|---|---|---|---|---|---|---|---|
| 310 | MAX. | – | 0.25 | 22.0 | 2.0 | 0.030 | 1.50 | 26.0 | 0.045 |
| MIN. | – | – | 19.0 | – | – | – | 24.0 | – | |
| GRADE | ELECTRICAL RESISTIVITY (N.M) | DENSITY (KG/M3) | SPECIFIC HEAT 0-1000C (J/KG.K) | ELASTIC MODULUS (GPA) | THERMAL CONDUCTIVITY (W/M.K) | MEAN COEFFICIENT OF THERMAL EXPANSION (M/M/0C) | |||
|---|---|---|---|---|---|---|---|---|---|
| AT 5000C | AT 1000C | 0-5380C | 0-3150C | 0-1000C | |||||
| 310 | 720 | 7750 | 500 | 200 | 18.7 | 14.2 | 17.0 | 16.2 | 15.9 |
| Changes in Price Extra 5 % |
|
|---|---|
| Export to | Shipping Time in Days |
| Taiwan | 15 |
| Cambodia | 9 |
| Chile | 45 |
| Venezuela | 45 |
| South Korea | 7 |
| Ecuador | 60 |
| Japan | 7 |
| Sri Lanka | 5 |
| Bolivia | 45 |
| Argentina | 45 |
| Maldives | 7 |
| Colombia | 45 |
| Brazil | 45-60 |
| Bangladesh | 14 |
| Mayanmar | 25 |
