Stainless Steel 316 Flanges

Home|Stainless Steel 316 Flanges
Stainless Steel 316 Flanges Specification
Top 5 Reasons for Suppliers in Algeria to Procure Stainless Steel 316 Flanges from Manisha Steel Centre
Reason Explanation
Quality Assurance Premium material
Timely Delivery On-time shipping
Competitive Pricing Cost-effective
Customer Support Reliable service
Wide Range Variety of sizes
Manisha Steel Centre

Table of Content


Stainless Steel 316 Flanges Specification
SS 316 Flange Sizes

SS 316 Flange Sizes

  • NPS: 1/2 - 60 inches
  • Class / Pressure: 150 - 2500 #
  • SCH: Sch 5 to Sch XXS

ASME SA 182 F316 Slip On Flange Manufacturing Process

ASME SA 182 F316 Slip On Flange Manufacturing Process

  • Rolling/ Casting
  • Cutting
  • Forging
UNS S31600 Weld Neck Flanges Face

UNS S31600 Weld Neck Flanges Face

  • LJF
  • T&G
  • RF
  • FF
  • RTJ
SS 316 Blind Flanges Threads

SS 316 Blind Flanges Threads

  • NPT
  • BSPT
  • FNPT
  • BSPP
  • MNPT
Stainless Steel 316 Socket Weld Flanges Standards

Stainless Steel 316 Socket Weld Flanges Standards

  • ASME SA182 | ASTM A182
  • MSS SP44
  • ASME B16.47 Series A & B
  • ASME B16.5
316 Flanges Types

316 Flanges Types

  • Lap Joint
  • Socket Weld
  • Blind
  • Weld Neck
  • Slip On
SA182 F316 Weld Neck Flange Finish

SA182 F316 Weld Neck Flange Finish

  • Serrated/Spiral
  • Smooth
  • Mirror
  • Concentric
INOX 316 Pipe Flange Testing

INOX 316 Pipe Flange Testing

  • Pressure
  • PMI
  • Hardness
  • Tensile
SUS 316 Puddle Flange Supporting Material

SUS 316 Puddle Flange Supporting Material

  • Ring Joint
  • Gaskets
  • Flange Bolts
WNR 1.4401 Exhaust Flange Features

WNR 1.4401 Exhaust Flange Features

  • excellent strength
  • corrosion-resistant
  • toughness

ASTM A182 F316 Threaded Flanges Connection Type

ASTM A182 F316 Threaded Flanges Connection Type

  • Welded
  • Bolted
  • Threaded
316 Stainless Steel Header Flanges Origin

316 Stainless Steel Header Flanges Origin

  • European
  • Indian
  • Japan, Korean
SS 316 Blind Flanges Meet Requirement

SS 316 Blind Flanges Meet Requirement

  • NACE MR0175/ MR0103
  • Sour Service
  • ISO 15156

Flange 316 Application

Flange 316 Application

  • Food and Beverage Industry
  • Pressure Vessels
  • Chemical Processing
  • Aerospace

WNR 1.4401 Socket Weld Flange Heat Treatment
Heat Treatment 650°C Stress Relief Treatment
1100°C Solution Treatment
1010 To 1120°C Annealing Treatment

Best Manufacturer Of ASTM A182 F316 Blind Flange in India Since 1997 At Lowest Price

Stainless Steel 316 Flanges Price List

Would You Like to View the Most Recent 316 Stainless Steel Flange Price List? For a quote right now, send an email to kalpesh@manishasteelcentre.com.

Approx. Wt /Unit Size Price In Saudi Riyal Price In US Price In UAE
11.88 DN150 SAR 382.01 US $101.75 AED 373.73
30.86 DN250 SAR 1023.48 US $272.61 AED 1001.30
20.92 DN200 SAR 770.51 US $205.23 AED 753.81
0.49 DN15 SAR 25.08 US $6.68 AED 24.54
1.29 DN32 SAR 56.95 US $15.17 AED 55.72
0.66 DN20 SAR 29.88 US $7.96 AED 29.24
5.23 DN80 SAR 204.05 US $54.35 AED 199.63
2.77 DN50 SAR 92.32 US $24.59 AED 90.32
0.99 DN25 SAR 39.98 US $10.65 AED 39.12
9.20 DN125 SAR 275.019 US $73.25 AED 269.05
4.26 DN65 SAR 114.55 US $30.51 AED 112.06
1.70 DN40 SAR 72.50 US $19.31 AED 70.93
7.78 DN100 SAR 247.23 US $65.85 AED 241.87

SS 316 Slip On and Weld Neck Flanges Supplier in Mumbai in Size 1/2 to 60" or Custom With Free and Die Forging MethodS

ASTM A182 F316 Blind FlangePressure Rating
ANSI /ASME B16.34 ANSI PRESSURE RATING CHART
°F Temperature 300 LBS 2500 LBS 400 LBS 900 LBS 150 LBS 1500 LBS 600 LBS
200 600 5000 800 1800 230 3000 1200
500 465 3880 620 1395 170 2330 930
300 540 4500 720 1620 205 2700 1080
-20 to 100 720 6000 960 2160 275 3600 1440
400 495 4140 660 1490 190 2485 995
600 435 3640 580 1310 140 2185 875
900 390 3240 520 1165 50 1945 780
750 415 3460 555 1245 95 2075 830
650 430 3580 575 1290 125 2150 860
700 425 3540 565 1275 110 2125 850
950 380 3180 510 1145 35 1910 765
850 395 3300 530 1190 65 1980 790
1150 200 1655 265 595 20 995 400
800 405 3360 540 1210 80 2015 805
1050 310 2570 410 925 20 1545 615
1000 320 2675 430 965 20 1605 640
1400 50 400 65 145 20 240 95
1100 255 2145 345 770 20 1285 515
1300 85 715 115 255 20 430 170
1200 155 1285 205 465 20 770 310
1500 25 230 35 80 10 135 55
1350 60 515 80 185 20 310 125
1450 35 285 45 105 15 170 70
1250 115 945 150 340 20 565 225

Buy WNR 1.4401 Socket Weld and Puddle Flange With Different Pressure Class 150 to 2500 LBS As Per ANSI B16.5

316 Stainless Steel Threaded Flange Weight Chart
NPS Socket
Weld		 Slip
On		 Lap
Joint		 Thd Weld
Neck		 Blind
1¼ 4.5 4.5 4.5 4.5 4.5 4.5
24 666 666 746.6 666 948.2 944.6
1/2 2.7 2.7 2.7 2.7 3.2 1.8
1½ 6.3 6.3 6.3 6.3 6.3 6.3
3/4 2.7 2.7 2.7 2.7 3.2 2.7
2½ 13.9 13.9 11.3 13.9 13.9 14.4
1 3.4 3.4 3.4 3.4 3.8 4.1
5 37.4 37.4 36.5 37.4 38.7 39.2
2 9.9 9.9 9.5 9.9 10.8 11.3
8 77.4 77.4 85.5 77.4 84.2 90
3 16.2 16.2 13.0 16.2 16.2 15.8
10 110.3 110.3 124.7 110.3 120.6 130.5
4 23.9 23.9 22 23.9 23.9 24.3
16 206.6 206.6 219.6 206.6 308.3 278.6
6 49.5 49.5 47.3 49.5 49.5 51.8
14 180 180 186.8 180 252.9 234
12 146.7 146.7 166 146.7 167.4 186.8
20 356.4 356.4 390.6 356.4 523.8 498.2
18 291.2 291.2 301.5 291.2 415.8 396
Stainless Steel 316 Flanges Sizes

Stainless Steel 316 Flanges Manufacturer in India providing a range of sizes with distinctive surface finishes and threading

Nominal Pipe Size Outside Diameter of Flange Diameter of Hub at Base Diameter of Raised Face Length Thru Hub Diameter of Hub at Bevel Diameter or Bore
Welding Neck Slip-On Threaded Socket Lap Joint Slip-on Socket Lap Joint
O X R Y Y Y H W B
16 23-1/2 18 18-1/2 5 2-1/2 3-7/16 16.00 16.16 16.19
6 11 7-9/16 8-1/2 3-1/2 1-9/16 1-9/16 6.63 6.72 6.75
1 4-1/4 1-15/16 2 2-3/16 11/16 11/16 1.32 1.36 1.38
1/2 3-1/2 1-3/16 1-3/8 1-7/8 5/8 5/8 .84 .88 .90
12 19 14-3/8 15 4-1/2 2-3/16 2-3/16 12.75 12.88 12.92
14 21 15-3/4 16-1/4 5 2-1/4 3-1/8 14.00 14.14 14.18
3-1/2 8-1/2 4-13/16 5-1/2 2-13/16 1-1/4 1-1/4 4.00 4.07 4.10
3/4 3-7/8 1-1/2 1-11/16 2-1/16 5/8 5/8 1.05 1.09 1.11
2 6 3-1/16 3-5/8 2-1/2 1 1 2.38 2.44 2.46
1-1/4 4-5/8 2-5/16 2-1/2 2-1/4 13/16 13/16 1.66 1.70 1.72
3 7-1/2 4-1/4 5 2-3/4 1-3/16 1-3/16 3.50 3.57 3.60
1-1/2 5 2-9/16 2-7/8 2-7/16 7/8 7/8 1.90 1.95 1.97
5 10 6-7/16 7.5/16 3-1/2 1-7/16 1-7/16 5.56 5.66 5.69
2-1/2 7 3-9/16 4-1/8 2-3/4 1-1/8 1-1/8 2.88 2.94 2.97
8 13-1/2 9-11/16 10-5/8 4 1-3/4 1-3/4 8.63 8.72 8.75
4 9 5-5/16 6-3/16 3 1-5/16 1-5/16 4.50 4.57 4.60
24 32 26-1/8 27-1/4 6 3-1/4 4-3/8 24.00 24.25 24.25
20 27-1/2 22 23 5-11/16 2-7/8 4-1/16 20.00 20.20 20.25
Keep Ready Stock Of Hot and Cold Forged UNS S31600 Threaded Flanges Suitable For Low Pressure Applications
ASTM A182 316 Slip On Flange Applications
ASTM A182 316 Slip On Flange Applications
  • Structural Applications
  • Sea Water
  • Pharmaceutical
  • Oil and Gas
  • Food Processing
  • Petrochemical
  • Marine
  • Construction
Top 6 Advantages of UNS S31600 Exhaust Flanges
  • High-Temperature Resistance
  • Corrosion Resistance
  • Durability
  • Strength
  • Easy to Maintain
  • Versatility
Connection Types of SS 316 Flange

Manisha Steel Centre Leading Stainless Steel 316 Flanges Supplier in India offers a variety of types, coatings, and pressure ratings.

Stainless Steel 316 Socket Weld Flanges

Stainless Steel 316 Socket Weld Flanges

SS 316 Blind Flanges

SS 316 Blind Flanges

AISI 316 Lap Joint Flange

AISI 316 Lap Joint Flange

ASME SA 182 F316 Slip On Flange

ASME SA 182 F316 Slip On Flange

UNS S31600 Weld Neck Flanges

UNS S31600 Weld Neck Flanges

WNR 1.4401 Exhaust Flanges

WNR 1.4401 Exhaust Flanges

ASTM A182 F316 Threaded Flanges

ASTM A182 F316 Threaded Flanges

SUS 316 Puddle Flange

SUS 316 Puddle Flange

316 Stainless Steel Header Flanges

316 Stainless Steel Header Flanges

ASME SA 182 F316 Orifice Flange Dimensions
NPS OUT
SIDE
DIA		 HUB
DIA		 MIN
THK
FLG		 DIA
RF		 HUB
DIA		 HGT
FLG		 DIA OF
TAB
O A T R X H Tg
1 125 33.4 36.6 50.8 54 81 6.4
8 380 219.1 39.7 269.9 260 110 12.7
1.1/2 155 48.3 36.6 73.0 70 84 6.4
2 165 60.3 36.6 92.1 84 84 6.4
4 255 114.3 36.6 157.2 146 90 12.7
2.1/2 190 73.0 36.6 104.8 100 87 6.4
10 445 273.0 46.1 323.8 321 116 12.7
3 210 88.9 36.6 127.0 117 87 9.5
16 650 406.4 55.6 469.9 483 144 12.7
6 320 168.3 36.6 215.9 206 98 12.7
18 710 457.0 58.8 533.4 533 157 12.7
12 520 323.8 49.3 381.0 375 129 12.7
20 775 508.0 62.0 584.2 587 160 12.7
14 585 355.6 52.4 412.8 425 141 12.7
24 915 610.0 68.3 692.2 702 167 12.7
Offer 316 Stainless Steel Forged Flanges With Different Face and Mechanical Testing Like Radiography, NDT, PMI etc.Refer HSN Code
SUS 316 Lap Joint Flange Testings
Test (Destructive , Non Destructive)
Chemical Analysis Spectro Analysis Radiography Test
Micro Test Dye Penetrant Test (DP Test)
Macro Test Ultra Sonic Test (UT)
Pitting Resistance Test Eddy Current Testing
Intergranular Corrosion (IGC) Test Impact Test
Flaring Test Bend Test
Flattening Test NDT Test
HIC Test Hydrostatic Test
AISI 316 Weld Neck Flanges HSN Code
HSN code
SS 316 73072100
How do you Maintain 316 Stainless Steel Flanges to Prevent Corrosion?
  • Regular Cleaning
  • Use Proper Sealants
  • Inspect for Damage
  • Avoid Exposure to Harsh Chemicals
  • Ensure Proper Installation
  • Protect Against Galvanic Corrosion
  • Maintain Low Temperatures in Aggressive Environments
Physical Properties of WNR 1.4401 Socket Weld Flange
Property 316 Stainless Steel Flange
Thermal Conductivity 16.3 W/m·K at 100°C
Melting Point 1375 to 1400°C (2500 to 2550°F)
Specific Heat 500 J/kg·K at 25°C
Density 8.00 g/cm³
Electrical Resistivity 0.72 µΩ·m
Modulus of Elasticity 193 GPa
Poisson's Ratio 0.3
Coefficient of Thermal Expansion 16.0 µm/m·K
Chemical Composition of Stainless Steel 316 Forged Flanges
Cr 18- 20%
Si 1%
C 0.08%
Ni 8-11%
Mn 2%
P 0.045%
Equivalent Grades of SS 316 Puddle Flange
Grade Old British UNS No Japanese JIS Swedish SS Euronorm
BS En No Name
316 304S31 58E S31600 SUS 316 2332 1.4301 X5CrNi18-10
Mechanical Properties of Stainless Steel 316 Header Flanges
Material Temperature Heat Tensile Strength Elongation %, Min Yield Strength
Min. Treatment Ksi (MPa), Min. Ksi (MPa), Min.
º F(º C)
TP316 1900 (1040) Solution 75(515) 35 30(205)
Stock on Hand of 316 SS Flange
Customized High Quality Stainless Steel 316 Weld Neck Flange

Customized High Quality Stainless Steel 316 Weld Neck Flange

2inch SS 316 Blind Flange

2inch SS 316 Blind Flange

24 inch SS 316 Slip on Flange

24 inch SS 316 Slip on Flange

3/4 Stainless Steel 316 Weld Neck Pipe Flange

3/4" Stainless Steel 316 Weld Neck Pipe Flange

ASME B16.5 Large Diameter 316 Stainless Steel Forged Flange

ASME B16.5 Large Diameter 316 Stainless Steel Forged Flange

Shipping Time as per Location of Stainless Steel 316 Flanges
Changes in Price
Extra 5 %
Export to Shipping Time in Days
Indonesia 9
UAE 5 days
Belgium 5
Kuwait 10
Germany 7
Philippines 14
Bahrain 9
France 30
Saudi Arabia 7
USA 40-60
Malaysia 10
Singapore 8
Netherland 30
Italy 30
South Africa 25-30
Manisha Steel Centre



Why Us ?
  • Stockist and Exporter of Small Diameter Tubing in Grades of Austenitic and Ferritic Stainless Steel.
  • Supply as Per American and European Standards According to Dimensional Standard ASME B36.19M
  • Distributor and Trader in Mumbai of Renowned Mills Outokumpu, POSCO and Aperam
  • Associated With Dealers and Stockholders in Kuwait, Nigeria, Iraq, Egypt, Congo and Gabon
©2025 Manisha Steel Centre. All Rights Reserved
Website Designed And SEO by Mesotek
Manufacturer and Supplier of Seamless Steel Tubes in India as per ASME SA 269.
