Table of Content
Alloy 825 Flanges Sizes
Incoloy 825 Blind Flanges Manufacturing Process
Alloy 825 Slip On Flange Face
UNS N08825 Weld Neck Flanges Threads
UNS N08825 Weld Neck Flanges Standards
UNS N08825 Weld Neck Flanges Types
UNS N08825 Weld Neck Flanges Finish
UNS N08825 Weld Neck Flanges Testing
WNR 2.4858 Socket Weld Flanges Supporting Material
WNR 2.4858 Socket Weld Flanges Grades
WNR 2.4858 Socket Weld Flanges Connection Type
WNR 2.4858 Socket Weld Flanges Origin
WNR 2.4858 Socket Weld Flanges Meet Requirement
WNR 2.4858 Socket Weld Flanges Application
For Updated Incoloy 825 Flanges Price List. Directly Contact Us and Obtain a Quote Right Away
| Standard | Class | Bolt Circle Diameter | Diameter | Bolt Size | Diameter of Bolt Hole | Number of Bolts |
|---|---|---|---|---|---|---|
| ANSI B16.5 Flanges | ANSI 150 Flange | 89 | 117 | 13 | 16 | 4 |
| ANSI 300 Flange | 98 | 133 | 16 | 19 | 4 | |
| ANSI 600 Flange | 98 | 133 | 16 | 19 | 4 | |
| ANSI 900 Flange | 111 | 159 | 22 | 25 | 4 | |
| ANSI 1500 Flange | 111 | 159 | 22 | 25 | 4 | |
| AS 2129 Flange | Table C Flange | 87 | 120 | 13 | 14 | 4 |
| Table D Flange | 87 | 120 | 13 | 14 | 4 | |
| Table E Flange | 87 | 120 | 13 | 14 | 4 | |
| Table F Flange | 98 | 135 | 16 | 18 | 4 | |
| Table H Flange | 98 | 135 | 16 | 18 | 4 | |
| Table J Flange | 98 | 135 | 16 | 18 | 4 | |
| AS4087 Flanges | PN14 Flanges | 87 | 120 | M12 | 14 | 4 |
| ISO 7005 (DIN) Flange | PN6 Flange | 90 | 120 | M12 | 14 | 4 |
| PN10 Flange | 100 | 140 | M16 | 18 | 4 | |
| PN16 Flange | 100 | 140 | M16 | 18 | 4 | |
| PN20 Flange | 89 | 120 | M14 | 16 | 4 | |
| PN25 Flange | 100 | 140 | M16 | 18 | 4 | |
| PN40 Flange | 100 | 140 | M16 | 18 | 4 |
Incoloy 825 Flanges Manufacturer in India in different sizes with a range of threads and surface finishes.
| Temp. °C | Class 150 | Class 300 | Class 400 | Class 600 | Class 900 | Class 1500 | Class 2500 |
|---|---|---|---|---|---|---|---|
| 150 | 15.8 | 50.3 | 66.8 | 100.3 | 150.6 | 250.8 | 418.2 |
| 200 | 13.8 | 48.3 | 64.5 | 96.7 | 145.0 | 241.7 | 402.8 |
| -29~38 | 20.0 | 51.7 | 68.9 | 103.4 | 155.1 | 258.6 | 430.9 |
| 325 | 9.3 | 41.4 | 55.0 | 82.6 | 124.0 | 206.6 | 344.3 |
| 350 | 8.4 | 40.3 | 53.6 | 80.4 | 120.7 | 201.1 | 335.3 |
| 250 | 12.1 | 46.3 | 61.7 | 92.7 | 139.0 | 231.8 | 386.2 |
| 50 | 19.5 | 51.7 | 68.9 | 103.4 | 155.1 | 258.6 | 430.9 |
| 100 | 17.7 | 51.5 | 68.7 | 103.0 | 154.6 | 257.6 | 429.4 |
| 300 | 10.2 | 42.9 | 57.0 | 85.7 | 128.6 | 214.4 | 357.1 |
Do You Want to See the Most Up-to-Date List of Prices for Incoloy 825 Flanges? To obtain a quote immediately, send an email to kalpesh@manishasteelcentre.com.
| Dimensions & DN & (Nominal Diameter) in mm | |||
|---|---|---|---|
| 1 1/2 | 40 | 18 | 450 |
| 2 | 50 | 20 | 500 |
| 2 1/2 | 65 | 24 | 600 |
| 1 | 25 | 15 | 375 |
| 1 1/4 | 32 | 16 | 400 |
| 3 | 80 | 28 | 700 |
| 8 | 200 | 36 | 900 |
| 10 | 250 | ||
| 4 | 100 | 30 | 750 |
| INCH | DN | INCH | DN |
| 1/2 | 15 | 12 | 300 |
| 3/4 | 20 | 14 | 350 |
| 5 | 125 | 32 | 800 |
| Full name | Short name |
|---|---|
| Special metals Incoloy 825 lap joint flanges | LJ |
| Inconel 825 large and small tongue and groove flanges | T&G |
| Alloy 825 raised face flanges | RF |
| Incoloy 825 alloy ring joint flanges | RTJ |
| Incoloy 825 nickel male and female flanges | M&F |
| Incoloy 825 flat face flanges | FF |
Manisha Steel Centre ISO Certified Alloy 825 Flanges Supplier in India Keep providing a range of pressure ratings and finishes.
Incoloy 825 Blind Flanges
Alloy 825 Slip On Flange
UNS N08825 Weld Neck Flanges
WNR 2.4858 Socket Weld Flanges
Nickelvac 825 Threaded Flanges
Inconel Alloy 825 Lap Joint Flange
Nickel 825 Exhaust Flanges
Inconel 825 Header Flanges
Inconel 825 Puddle Flange
| Element | Electrical Resistivity | Specific Heat | Melting Point | Hardness | Yield Strength (0.2%Offset) | Tensile Strength | Thermal Conductivity | Elongation | Density | Modulus of Elasticity |
|---|---|---|---|---|---|---|---|---|---|---|
| 825 | 1.13 μ cm | 440 J/kg-°K | 1400 °C, 2550 °F | Rockwell B : 135-165 | 32,000 Psi, 220 MPa | 80,000 Psi 550 MPa | 11.3 W/m-°K | 30 % | 8.14 g/cm3 | 196 MPa |
| 800H / 800 /800HT | 99 Microhm-cm | 460 J/kg-°K | 2525 °F 1385 °C | Brinell : 126 | 205 MPa 30,000 Psi | 75,000 Psi 520 MPa | 18.3 W/m-°K | 30 % | 7.94 g/centimeter3 | 196.5 GPa |
| Grade | Germany | North America | OR | Russia | France | British Standard | Europe | Japan |
|---|---|---|---|---|---|---|---|---|
| WERKSTOFF NR. | UNS | OR | GOST | AFNOR | BS | EN | JIS | |
| Incoloy 825 | 2.4858 | N08825 | XH38BT | ЭП703 | NFE30C20DUM | NA 16 | NiCr21Mo | NCF 825 |
| Incoloy 800 | 1.4876 | N08800 | XH32T | ЭИ670 | Z8NC32-21 | NA 15 | X10NiCrAlTi32-20 | NCF 800 |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | XH32T | ЭИ670 | Z8NC33-21 | NA 15(H) | X5NiCrAlTi31-20 | NCF 800H |
| Incoloy 800HT | 1.4876/1.4859 / | N08811 | XH32T | ЭИ670 | - | NA 15(HT) | X8NiCrAlTi32-21 | NCF 800HT |
| Grade | Mn | C | Fe | Cr | Si | S | Ti | Al | Cu | Ni |
|---|---|---|---|---|---|---|---|---|---|---|
| 800H | 1.50 max | .05 to .10 | 39.50 min | 19 to 23 | 1 max | .015 max | .15 to .60 | .15 to .60 | .75 max | 30 to 35 |
| 825 | 1 max | .05 max | 22 min | 19.50 to 23.50 | .5 max | .03 max | .06 to 1.20 | .02 max | 1.50 to 3 | 38 to 46 |
| 800 | 1.50 max | .10 max | 39.50 min | 19 to 23 | 1 max | .015 max | .15 to .60 | .15 to .60 | .75 max | 30 to 35 |
| 800HT | 1.50 max | .06 to .10 | 39.50 min | 19 to 23 | 1 max | .015 max | .15 to .60ᴬ | .15 to .60ᴬ | .75 max | 30 to 35 |
| Changes in Price Extra 5 % |
|
|---|---|
| Export to | Shipping Time in Days |
| Trinidad And Tobago | 60 |
| Costa Rica | 45 |
| Mexico | 45 |
| Jamaica | 50 |
| Panama | 45 |
| Equatorial Guinea | 45-60 |
| Puerto Rica | 45 |
| Norway | 45 |
| Germany | 21 |
| Canada | 45 |
| The Republic Of Congo | 45-60 |
| Gabon | 45-60 |
| Bahamas | 60 |
| Denmark | 35 |
| Russia | 20 |
