High Performance Incoloy® Alloy 20 Forged Flanges Manufacturer in India As Per ASME B16.5

Alloy 20 Flanges Specification

Alloy 20 Blind Flanges Sizes

NPS:1/2" to 48
SCH:Sch 10s - Sch XXS
Class:150, 600, 1500, 2500#, PN10, PN25, PN40

Incoloy® Alloy 20 Slip On Flange Manufacturing Process

Casting
Forging
Rolling/Cutting

20Cb-3 Lap Joint Flange Face

UNS N08825 Weld Neck Flanges Threads

MNPT
FNPT
NPT
BSPP
BSPT

WNR 2.4660 Socket Weld Flanges Standards

ANSI/ASME B16.5 , B16.48
BS4504

Carpenter 20 Threaded Flanges Types

Lap Joint
Blind
Weld Neck
Slip On
Socket Weld

Incoloy® 20 Exhaust Flanges Finish

Mirror
Smooth
Serrated
Concentric/Spiral

Nickel Alloy 20 Header Flanges Testing

Pressure
Hardness
PMI
Tensile

NiCr20CuMo Puddle Flange Supporting Material

Gaskets
Flange Bolts
Ring Joint

ASTM B462 UNS N08020 Flange

F22 , F91
F1 , F5
F9 , F11

WNR 2.4858 Socket Weld Flanges Connection Type

Alloy 20 Flanges Connection Type

Threaded
Bolted
Welded

Alloy 20 Blind Flanges Origin

European
Indian
Japan, Korean

WNR 2.4858 Socket Weld Flanges Meet Requirement

Incoloy® Alloy 20 Slip On Flange Meet Requirement

NACE MR0103/MR0175
Sour Service
ISO 15156

WNR 2.4858 Socket Weld Flanges Application

UNS N08020 Weld Neck Flanges Application

Marine
Chemical processing
Oil and gas
Food processing

Superior ASTM B462 UNS N08020 Slip On and Weld Neck Flanges Supplier in Mumbai As Per Custom Drawing

Alloy 20 Flanges Size

Do You Want to See the Most Up-to-Date List of Prices for Incoloy 825 Flanges? To obtain a quote immediately, send an email to kalpesh@manishasteelcentre.com.

NPS (.in)	As Per ASME B16.5 Class 150
Flange Diameter In (.in)	Bolts Number	Bolt Diameter In (.in)	Bolt Holes (B.H.) Diameter In (.in)	Bolt Circle (B.C.) In(.in)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
3/4	3-7/8	4	1/2	0.62	2-3/4
2-1/2	7	4	5/8	0.75	5-1/2
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1	4-1/4	4	1/2	0.62	3-1/8
2	6	4	5/8	0.75	4-3/4
1-1/2	5	4	1/2	0.62	3-7/8
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
12	19	12	7/8	1	17
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4

Incoloy® Alloy 20 Slip On Flange Dimensions

Alloy 20 Flanges Manufacturer in India in a range of sizes with distinct threads and surface finishes.

Nom. Pipe Size	R	O	T	X	Bolt Circle Dia.	No./Dia. of Holes	B2	L	B	r	B3	L2	H	D	L3
2	3.62	6	0.75	3.06	4.75	4-0.75	2.07	1	2.44	0.31	2.46	2.5	2.38	0.69	1
18	21	25	1.56	19.88	22.75	16-1.25	17.25	2.69	18.18	0.5	18.2	5.5	18	1.94	3.81
20	23	27.5	1.69	22	25	20-1.25	19.25	2.88	20.2	0.5	20.25	5.69	20	2.13	4.06
22	25.25	29.5	1.81	24.25	27.25	20-1.38	21.25	3.13	22.22	0.5	22.25	5.88	22	2.38	4.25
24	27.25	32	1.88	26.12	29.5	20-1.38	23.25	3.25	24.25	0.5	24.25	6	24	2.5	4.38
2-1/2	4.12	7	0.88	3.56	5.5	4-0.75	2.47	1.12	2.94	0.31	2.97	2.75	2.88	0.75	1.12
3-1/2	5.5	8.5	0.94	4.81	7	8-0.75	3.55	1.25	4.07	0.38	4.1	2.81	4	0.88	1.25
4	6.19	9	0.94	5.31	7.5	8-0.75	4.03	1.31	4.57	0.44	4.6	3	4.5	0.94	1.31
5	7.31	10	0.94	6.44	8.5	8-0.88	5.05	1.44	5.66	0.44	5.69	3.5	5.56	0.94	1.44
3	5	7.5	0.94	4.25	6	4-0.75	3.07	1.19	3.57	0.38	3.6	2.75	3.5	0.81	1.19
1-1/2	2.88	5	0.68	2.56	3.88	4-0.62	1.61	0.88	1.95	0.25	1.97	2.44	1.9	0.62	0.88
6	8.5	11	1	7.56	9.5	8-0.88	6.07	1.56	6.72	0.5	6.75	3.5	6.63	1.06	1.56
8	10.62	13.5	1.12	9.69	11.75	8-0.88	7.98	1.75	8.72	0.5	8.75	4	8.63	1.25	1.75
1/2	1.38	3.5	0.44	1.19	2.38	4-0.62	0.62	0.62	0.88	0.12	0.9	1.88	0.84	0.38	0.62
3/4	1.69	3.88	0.5	1.5	2.75	4-0.62	0.82	0.62	1.09	0.12	1.11	2.06	1.05	0.44	0.62
1	2	4.25	0.56	1.94	3.12	4-0.62	1.05	0.69	1.36	0.12	1.38	2.19	1.32	0.5	0.69
1-1/4	2.5	4.62	0.62	2.31	3.5	4-0.62	1.38	0.81	1.7	0.19	1.72	2.25	1.66	0.56	0.81
10	12.75	16	1.19	12	14.25	12-1.00	10.02	1.94	10.88	0.5	10.92	4	10.75	1.31	1.94
12	15	19	1.25	14.38	17	12-1.00	12	2.19	12.88	0.5	12.92	4.5	12.75	1.56	2.19
14	16.25	21	1.38	15.75	18.75	12-1.12	13.25	2.25	14.14	0.5	14.18	5	14	1.63	3.12
16	18.5	23.5	1.44	18	21.25	16-1.12	15.25	2.5	16.16	0.5	16.19	5	16	1.75	3.44

Get Extensive Range of WNR 2.4660 Blind and Socket Weld Flanges With Sch 5 to XXS Online

UNS N08020 Weld Neck Flanges Schedule Chart

Nominal Pipe Size	Socket Weld Flange	Blind Flange	Slip On Flange	Threaded Flange	Weld Neck Flange	Lap Joint Flange
2	5	5	5	5	6	5
2½	8	7	8	8	10	8
3	9	9	9	9	11.5	9
3½	11	13	11	12	12	11
4	13	17	13	13	16.5	13
24	220	430	220	220	268	275
5	15	20	15	15	21	15
22	185	355	185	185	225	245
1½	3	4	3	3	4	3
12	64	123	64	64	88	64
6	19	27	19	19	26	19
18	130	220	130	130	165	160
20	165	285	165	165	197	195
14	90	140	90	90	114	105
16	98	180	106	98	140	140
8	30	47	30	30	42	30
10	43	70	43	43	54	43
½	2	2	1	1	2	1
¾	2	2	2	2	2	2
1	2	2	2	2	3	2
1¼	3	3	3	3	3	3

Shop Premium Quality Carpenter 20 Threaded Flanges With NDT and PMI Testing At Most Affordable Price

ASTM B462 UNS N08020 Flange Tested Properties

Hydrostatic testing machine
Ultrasonic flaw detector
Magnetic particle detector
Direct-reading Spectrograph
X-ray detector

Alloy 20 Flanges Prices

For Updated Incoloy 825 Flanges Price List. Directly Contact Us and Obtain a Quote Right Away

Alloy 20 Flanges Types

Manisha Steel Centre ISO Certified Alloy 20 Flanges Supplier in India Keep providing a range of pressure ratings and finishes

Alloy 20 Blind Flanges

Incoloy® Alloy 20 Slip On Flange

UNS N08020 Weld Neck Flanges

WNR 2.4660 Socket Weld Flanges

Carpenter 20 Threaded Flanges

20Cb-3 Lap Joint Flange

Incoloy® 20 Exhaust Flanges

Nickel Alloy 20 Header Flanges

NiCr20CuMo Puddle Flange

Choose From Our Selection of 20Cb-3 Pipe Flanges Suitable For Petrochemical, Chemical and Power Generation Plants

Nickel Alloy 20 Header Flanges Applications

Food processing
Marine
Chemical processing
Power Generation
Petrochemical
Pharmaceuticals

20Cb-3 Lap Joint Flange Mechanical

Grade	Yield Strength (0.2%Offset)		Tensile Strength		Elongation
Grade	(per square inch)	(megapascal)	(per square inch)	(megapascal)	%
Alloy 20 flanges	35000	241	80000	551	30

Carpenter 20 Threaded Flanges Equivalent

STANDARD	WERKSTOFF NR.	UNS	EN	AFNOR
Alloy 20 flange	2.4660	N08020	NiCr20CuMo	Z2NCUD31-20AZ

NiCr20CuMo Puddle Flange Chemical Composition

Grade	Carbon	Copper	Sulfur	Phosphorus	Manganese	Molybdenum	Iron	Chromium	Nickel	Niobium + Tantalum	Silicon
Nickel Alloy 20 Flange	0.07	3.00 to 4.00	0.035	0.045	2.00	2.00 to 3.00	Balance	19.00 to 21.00	32.00 -38.00	(8 x C) to 1.00	1.00

Alloy 20 Flanges Shipping Time and Delivery Location

Changes in Price Extra 5 %
Export to	Shipping Time in Days
Jamaica	50
Panama	45
Equatorial Guinea	45-60
Puerto Rica	45
Norway	45
Gabon	45-60
Russia	20
Bahamas	60
Denmark	35
Trinidad And Tobago	60
Costa Rica	45
Mexico	45
Germany	21
Canada	45
The Republic Of Congo	45-60
