To meet customer requirements, the ASTM A358 TP347H Pipe Manufacturer in India offers a large range of diameters and sizes.
| NPS Designator |
Outside Diameter | Nominal Wall Thickness | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| inch | mm | Schedule 10SA | Schedule 5SA | Schedule 80SA | Schedule 40SA | |||||
| in. | mm | in. | mm | in. | mm | in. | mm | |||
| 22 | 22.000 | 558.80 | 0.218B | 5.54B | 0.188 | 4.78 | … | … | … | … |
| 16 | 16.000 | 406.40 | 0.188B | 4.78B | 0.165 | 4.19 | … | … | … | … |
| 24 | 24.000 | 609.60 | 0.250 | 6.35 | 0.218 | 5.54 | … | … | … | … |
| 10 | 10.750 | 273.05 | 0.165 | 4.19 | 0.134 | 3.40 | 0.500B | 12.70B | 0.365 | 9.27 |
| 12 | 12.750 | 323.85 | 0.180 | 4.57 | 0.156 | 3.96 | 0.500B | 12.70B | 0.375B | 9.52B |
| 8 | 8.625 | 219.08 | 0.148 | 3.76 | 0.109 | 2.77 | 0.500 | 12.70 | 0.322 | 8.18 |
| 18 | 18.000 | 457.20 | 0.188B | 4.78B | 0.165 | 4.19 | … | … | … | … |
| 30 | 30.000 | 762.00 | 0.312 | 7.92 | 0.250 | 6.35 | … | … | … | … |
| 14 | 14.000 | 355.60 | 0.188B | 4.78B | 0.156 | 3.96 | … | … | … | … |
| 20 | 20.000 | 508.00 | 0.188B | 4.78B | 0.188 | 4.78 | … | … | … | … |
Many sizes and forms are available at reasonable costs from Manisha Steel Centre, an ASTM A358 TP347H pipe supplier in India.
ASTM A358 TP347H Class 5 EFW Pipe
ASME SA 358 TP 347H Electric Fusion Welded Pipe
A358 TP 347H Cl2 EFW Electric Fusion Welded Pipe
SA 358 Grade TP347H Class1 EFW Austenitic Chromium Nickel Stainless Steel Pipe
ASTM A358 GR TP347H Electric Fusion Straight Weld Pipe
ASME SA 358 TP 347H Class 3 Electric Fusion Welded Steel Pipe
SA 358 Grade TP347H EFW Welding Pipe
ASTM A358 Type 347H Cl4 EFW Stainless Steel Pipe
Would You Like to Purchase ASTM A358 TP347H Pipe at a Competitive Price? You can get an estimate immediately by sending an email. kalpesh@manishasteelcentre.com.
| Price List | Per Unit (INR) |
|---|---|
| ASTM A 358 GRADE TP347H pipe SIZE 114.30 Milimeter | 195 |
| ASTM A 312 GRADE TP347H SIZE SS PIPES Size: 48.26 Milimeter | 185 |
| Impact Test | Intergranular Corrosion (IGC) Test |
| Ultra Sonic Test (UT) | Hardness Test |
| Transverse Guided Bend Weld Test | Transverse Tension |
| Hydrostatic Test | Positive Material Identification – PMI Testing |
| Hydrogen Test | Chemical Analysis |
| Radiography Test | Micro Test |
| Bend Test | Flaring Test |
| Eddy Current Testing | Pitting Resistance Test |
| STANDARD | UNS | WERKSTOFF NR. | JIS | EN | GOST |
|---|---|---|---|---|---|
| SS 347H | S34709 | 1.4961 | SUS 347H | X6CrNiNb18-12 | - |
| SS Grade | Yield Strength | Tensile Strength | Elongation | Rockwell B | Brinell |
|---|---|---|---|---|---|
| SS 347H | 205 | 515 | 40 | 92 | 201 |
| Grade | Specific Heat 0-1000C | Density | Electrical Resistivity | Elastic Modulus | Thermal Conductivity | Mean Coefficient of Thermal Expansion | |||
|---|---|---|---|---|---|---|---|---|---|
| at 1000C | at 5000C | 0-1000C | 0-3150C | 0-5380C | |||||
| 347H | 500 J/kg.K | 8000 kg/m3 | 720 n.m | 193 GPa | 16.2 W/m.K | 21.5 W/m.K | 17.2 | 17.8 m/m/0C | 18.4 m/m/0C |
